JVC MX-GB5 Service Manual

3-14
Amp. board
Block No. [0][3][0][0]
UC103 2201-000389 C CAPACITOR 0.022nF
UC104 2201-000389 C CAPACITOR 0.022nF
UC105 2201-000565 C CAPACITOR 47nF
UC106 2201-000565 C CAPACITOR 47nF
UC107 2202-000796 C CAPACITOR 1nF
UC108 2202-000231 C CAPACITOR 0.33nF
UC109 2202-000780 C CAPACITOR 100nF
UCW7 3708-000193 CONNECTOR 17P
UCW01 3708-001577 CONNECTOR 30P
UCW02 AH39-00003B LEAD CONNECTOR
UCW03 AH39-00551A WIRE HARNESS 4P
UCW04 3708-000454 CONNECTOR 22P
UCW05 3711-000967 CONNECTOR BOX 4P
UCW06 3708-000181 CONNECTOR 16P
UCW7A 3708-001723 CONNECTOR 17P
UD03 1N4148 GE DIODE 0401-000101
UD101 1N4148 GE DIODE 0401-000101
UD102 1N4148 GE DIODE 0401-000101
UD103 1N4002 DIODE 0402-000127
UD104 1N4002 DIODE 0402-000127
UD105 1N4002 DIODE 0402-000127
UD106 1N4002 DIODE 0402-000127
UD107 1N4002 DIODE 0402-000127
UE101 2401-002180 E CAPACITOR 2.2uF 20% 50V
UE102 2401-000759 E CAPACITOR 220nF 20% 50V
UE103 2401-001355 E CAPACITOR 470uF 20% 10V
UE104 2401-000240 E CAPACITOR 100uF 20% 10V
UE105 2401-000475 E CAPACITOR 10uF 20% 50V
UE106 2401-000475 E CAPACITOR 10uF 20% 50V
UE107 2401-000240 E CAPACITOR 100uF 20% 10V
UQ101 KSC945 TRANSISTOR 0501-000398
UQ102 KSR1003 DIGI TRANSISTOR 0504-000118
UQ103 KSR1003 DIGI TRANSISTOR 0504-000118
UQ104 KSR1003 DIGI TRANSISTOR 0504-000118
UQ107 KSA928A-Y TRANSISTOR 0501-000610
UQ108 KSA928A-Y TRANSISTOR 0501-000610
UQ109 KSA928A-Y TRANSISTOR 0501-000610
UR02A 2001-000666 C RESISTOR 33OHM 5% 1/8W
UR101 2001-000449 C RESISTOR 2.2KOHM 5% 1/8W
UR102 2001-000734 C RESISTOR 4.7KOHM 5% 1/8W
UR103 2001-000508 C RESISTOR
220KOHM 5% 1/
8W
UR104 2001-000793 C RESISTOR 47OHM 5% 1/8W
UR105 2001-000295 C RESISTOR 10MOHM 5% 1/8W
UR106 2001-000850 C RESISTOR
560KOHM 5% 1/
8W
UR107 2001-000435 C RESISTOR 1MOHM 5% 1/8W
UR108 2001-000290 C RESISTOR 10KOHM 5% 1/8W
UR109 2001-000290 C RESISTOR 10KOHM 5% 1/8W
UR110 2001-000290 C RESISTOR 10KOHM 5% 1/8W
UR111 2001-000290 C RESISTOR 10KOHM 5% 1/8W
UR112 2001-000290 C RESISTOR 10KOHM 5% 1/8W
UR113 2001-000429 C RESISTOR 1KOHM 5% 1/8W
UR115 2001-000429 C RESISTOR 1KOHM 5% 1/8W
UR116 2001-000429 C RESISTOR 1KOHM 5% 1/8W
UR117 2001-000281 C RESISTOR 100OHM 5% 1/8W
UR118 2001-000429 C RESISTOR 1KOHM 5% 1/8W
UR119 2001-000429 C RESISTOR 1KOHM 5% 1/8W
UR120 2001-000734 C RESISTOR 4.7KOHM 5% 1/8W
UR121 2001-000290 C RESISTOR 10KOHM 5% 1/8W
UR122 2001-000281 C RESISTOR 100OHM 5% 1/8W
UR123 2001-000281 C RESISTOR 100OHM 5% 1/8W
UR124 2001-000281 C RESISTOR 100OHM 5% 1/8W
UR125 2001-000281 C RESISTOR 100OHM 5% 1/8W
UR126 2001-000281 C RESISTOR 100OHM 5% 1/8W
UR127 2001-000281 C RESISTOR 100OHM 5% 1/8W
UR128 2001-000281 C RESISTOR 100OHM 5% 1/8W
UR129 2001-000281 C RESISTOR 100OHM 5% 1/8W
UR130 2001-000290 C RESISTOR 10KOHM 5% 1/8W
UR131 2001-000290 C RESISTOR 10KOHM 5% 1/8W
UR132 2001-000290 C RESISTOR 10KOHM 5% 1/8W
UR133 2001-000290 C RESISTOR 10KOHM 5% 1/8W
UR134 2001-000290 C RESISTOR 10KOHM 5% 1/8W
UR135 2001-000290 C RESISTOR 10KOHM 5% 1/8W
UR136 2001-000290 C RESISTOR 10KOHM 5% 1/8W
UR137 2001-000786 C RESISTOR 47KOHM 5% 1/8W
UR138 2001-000281 C RESISTOR 100OHM 5% 1/8W
UR139 2001-000281 C RESISTOR 100OHM 5% 1/8W
 Symbol No. Part No. Part Name Description Local
UR140 2001-000290 C RESISTOR 10KOHM 5% 1/8W
UR141 2001-000281 C RESISTOR 100OHM 5% 1/8W
UR142 2001-000281 C RESISTOR 100OHM 5% 1/8W
UR143 2001-000034 C RESISTOR 220OHM 5% 1/4W
UR144 2001-000034 C RESISTOR 220OHM 5% 1/4W
UR145 2001-000034 C RESISTOR 220OHM 5% 1/4W
UR146 2001-000034 C RESISTOR 220OHM 5% 1/4W
UR147 2001-000034 C RESISTOR 220OHM 5% 1/4W
UR148 2001-000034 C RESISTOR 220OHM 5% 1/4W
UX101 2801-001394 CRYSTAL-UNIT 32.768KHz
UX102 2802-001198 C.RESONATOR 10MHZ 0.5%
XXXXX 2001-000290 C RESISTOR 10KOHM 5% 1/8W GB6
XXXXX AH41-00672A PCB FRONT
 Symbol No. Part No. Part Name Description Local
 FIC01 STK433-070 IC 1201-002090 GB5
 FIC01 STK403-090 IC 1201-002094 GB6
FIC02 BA4560 IC 1201-000191
 WIC01 STK412-230 IC 1201-002086 GB5
 WIC01 STK412-240 IC 1201-001958 GB6
R52 2001-000110 C RESISTOR 10OHM 5% 1/4W
AC36 2401-000438 E CAPACITOR 10uF 20% 25V
AC37 2401-001975 E CAPACITOR 47uF 20% 16V
AC41 2301-000375 M CAPACITOR 100nF
AC52 2401-001538 E CAPACITOR 47uF 20% 25V
AC10L 2202-000263 C CAPACITOR 470pF
AC10R 2202-000263 C CAPACITOR 470pF
AC11L 2202-000263 C CAPACITOR 470pF
AC11R 2201-000557 C CAPACITOR 0.47nF
AC12L 2201-000838 C CAPACITOR 0.003nF
AC12R 2201-000838 C CAPACITOR 0.003nF
AC13L 2301-000375 M CAPACITOR 100nF
AC13R 2301-000375 M CAPACITOR 100nF
AC20L 2202-000263 C CAPACITOR 470pF
AC20R 2202-000263 C CAPACITOR 470pF
AC21L 2201-000146 C CAPACITOR 0.1nF
AC21R 2201-000146 C CAPACITOR 0.1nF
AC22L 2201-000838 C CAPACITOR 0.003nF
AC22R 2201-000838 C CAPACITOR 0.003nF
AC25L 2301-000375 M CAPACITOR 100nF
AC25R 2301-000375 M CAPACITOR 100nF
AC30L 2301-000412 M CAPACITOR 22nF
AC30R 2301-000412 M CAPACITOR 22nF
AC33L 2301-000412 M CAPACITOR 22nF
AC33R 2301-000412 M CAPACITOR 22nF
AC50L 2301-000412 M CAPACITOR 22nF
AC50R 2301-000412 M CAPACITOR 22nF
AC51L 2301-000412 M CAPACITOR 22nF
AC51R 2301-000412 M CAPACITOR 22nF
AC603 2201-000783 C CAPACITOR 100nF
AC604 2201-000783 C CAPACITOR 100nF
AC607 2201-000532 C CAPACITOR 4.7nF
AC608 2201-000532 C CAPACITOR 4.7nF
ACE2 2202-000780 C CAPACITOR 100nF GB5
ACW1 3708-001167 CONNECTOR 14P
ACW2 3711-003113 CONNECTOR BOX 9P
ACW3 3711-000820 CONNECTOR BOX 2P
ACW4 3711-003409 CONNECTOR BOX 3P
AD100 1N4148 GE DIODE 0401-000101
AD101 1N4148 GE DIODE 0401-000101
AD102 1N4148 GE DIODE 0401-000101
AD103 1N4148 GE DIODE 0401-000101
AD104 1N4148 GE DIODE 0401-000101
AD105 1N4148 GE DIODE 0401-000101
AD303 1N4002 DIODE 0402-000127
AD304 1N4002 DIODE 0402-000127
AE100 2401-000357 E CAPACITOR 100uF 20% 50V
AE101 2401-001164 E CAPACITOR 33uF 20% 16V
 Symbol No. Part No. Part Name Description Local
