10
Connections
Using the AUX Connection
Connect the AUX IN socket at the rear of the unit to the line output sockets on the auxiliary
equipment using a 3.5 mm to 3.5 mm stereo audio cable (not included), as illustrated.
Using Earphones
Turn down the volume before connecting the earphones. Slowly raise the volume with the
earphones on until you reach your desired volume. When earphones are connected, the
speaker is automatically muted.
Rear of the Unit
UPDATE PORT
Auxiliary
Equipment
3.5 mm to 3.5 mm stereo
audio cable (Not included)
Rear of the Unit
UPDATE PORT
Long-term exposure to loud music may cause hearing damage. It is best to avoid extreme volume when
using earphones, especially for extended periods.
RA-D77M_IB_170608_will.indd 10 13/6/2017 4:32 PM
