JVC RX-5020VBK Service Manual

3-5
RX-5020VBK/RX-5022VSL
Item
Parts number Parts name Ar
e
a
Electrical parts list (Power amp board)
Remarks
Block No. 01
A
C 201 QFLC2AJ-104Z M CAPACITOR .10MF 5% 100V
C 202 QFLC2AJ-104Z M CAPACITOR .10MF 5% 100V
C 203 QFLC2AJ-104Z M CAPACITOR .10MF 5% 100V
C 204 QETM1VM-228 E.CAPACITOR 2200MF 20% 35V
C 205 QETM1VM-108 E.CAPACITOR 1000MF 20% 35V
C 206 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 207 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 208 QFLC2AJ-472Z M CAPACITOR 4700PF 5% 100V
C 209 QETN1EM-477Z E CAPACITOR 470MF 20% 25V
C 210 QCZ9104-472 C CAPACITOR
A
4700PF
C 212 QETN1CM-477Z E CAPACITOR 470MF 20% 16V
C 213 QETM0JM-228 E CAPACITOR 2200MF 20% 6.3V
C 218 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 301 QEHR1HM-106Z E CAPACITOR 10MF 20% 50V
C 302 QEHR1HM-106Z E CAPACITOR 10MF 20% 50V
C 303 QCS31HJ-271Z C CAPACITOR 270PF 5% 50V
C 304 QCS31HJ-271Z C CAPACITOR 270PF 5% 50V
C 305 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 306 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 307 QCB31HK-152Z C CAPACITOR 1500PF 10% 50V
C 308 QCB31HK-152Z C CAPACITOR 1500PF 10% 50V
C 309 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C 310 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C 311 QCS31HJ-100Z C CAPACITOR 10PF 5% 50V
C 312 QCS31HJ-100Z C CAPACITOR 10PF 5% 50V
C 313 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V
C 314 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V
C 315 QCS32HJ-220Z C CAPACITOR 22PF 5% 500V
C 316 QCS32HJ-220Z C CAPACITOR 22PF 5% 500V
C 317 QEHR1VM-476Z E CAPACITOR 47MF 20% 35V
C 318 QEHR1VM-476Z E CAPACITOR 47MF 20% 35V
C 319 QETN1JM-107Z E CAPACITOR 100MF 20% 63V
C 320 QETN1JM-107Z E CAPACITOR 100MF 20% 63V
C 321 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C 322 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C 323 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C 324 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C 325 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 326 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 327 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 328 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 501 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 503 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 504 QCS31HJ-470Z C CAPACITOR 47PF 5% 50V
C 505 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 506 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 507 QCS31HJ-470Z C CAPACITOR 47PF 5% 50V
C 511 QETN1CM-108Z E CAPACITOR 1000MF 20% 16V
C 512 QCBB1HK-223Y C CAPACITOR .022MF 10% 50V
C 521 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 522 QCZ0202-155Z ML C CAPA I/M 1.5MF
C 801 QEHR1HM-106Z E CAPACITOR 10MF 20% 50V
C 802 QEHR1HM-106Z E CAPACITOR 10MF 20% 50V
C 803 QCS31HJ-271Z C CAPACITOR 270PF 5% 50V
C 804 QCS31HJ-271Z C CAPACITOR 270PF 5% 50V
C 805 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 806 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 807 QCB31HK-152Z C CAPACITOR 1500PF 10% 50V
C 808 QCB31HK-152Z C CAPACITOR 1500PF 10% 50V
C 809 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C 810 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C 811 QCS31HJ-100Z C CAPACITOR 10PF 5% 50V
C 812 QCS31HJ-100Z C CAPACITOR 10PF 5% 50V
C 813 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V
C 814 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V
C 815 QCS32HJ-330Z C CAPACITOR 33PF 5% 500V
C 816 QCS32HJ-330Z C CAPACITOR 33PF 5% 500V
C 817 QEHR1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 818 QEHR1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 819 QEHR2AM-106Z E CAPACITOR 10MF 20% 100V
C 820 QEHR2AM-106Z E CAPACITOR 10MF 20% 100V
C 821 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C 822 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C 823 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C 824 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C 825 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 826 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 827 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 828 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 829 QETN1HM-476Z E CAPACITOR 47MF 20% 50V
C 830 QETN1HM-476Z E CAPACITOR 47MF 20% 50V
C 901 QEHR1HM-106Z E CAPACITOR 10MF 20% 50V
C 903 QCS31HJ-271Z C CAPACITOR 270PF 5% 50V
C 905 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 907 QCB31HK-152Z C CAPACITOR 1500PF 10% 50V
C 909 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C 911 QCS31HJ-100Z C CAPACITOR 10PF 5% 50V
C 913 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V
C 915 QCS32HJ-330Z C CAPACITOR 33PF 5% 500V
C 917 QEHR1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 919 QEHR2AM-106Z E CAPACITOR 10MF 20% 100V
C 921 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C 923 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V
C 925 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 927 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 929 QETN1HM-476Z E CAPACITOR 47MF 20% 50V
CN201 QGF1205C1-14 CONNECTOR
CN203 QGD2501C1-05Z SOCKET I.M
CN241 QGD2501C1-05Z SOCKET I.M
CN251 QGA3901F2-03 CONNECTOR
CN291 QGB2510J1-04 CONNECTOR
CN292 QGB2510K1-04 CONNECTOR
CN301 QGB2510K1-14 CONNECTOR
CN302 QGB2510K1-14 CONNECTOR
CN492 QGB2510K1-04 CONNECTOR
CN501 QGB2510K1-07 CONNECTOR
CN801 QGB2510K1-14 CONNECTOR
CN802 QGB2510K1-14 CONNECTOR
CN901 QGB2510K1-14 CONNECTOR
C1331 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C1332 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
D 201 10E2-FD DIODE
A
D 202 11ES2-T4 DIODE I.M
A
D 203 10E2-FD DIODE
A
D 204 11ES2-T4 DIODE I.M
A
D 206 11ES2-T4 DIODE I.M
A
D 207 11ES2-T4 DIODE I.M
A
D 208 11ES2-T4 DIODE I.M
A
D 209 11ES2-T4 DIODE I.M
A
D 210 1SS133-T2 SI DIODE IM
D 211 MTZJ6.8C-T2 Z DIODE I/M
D 212 11ES2-T4 DIODE I.M
D 217 MTZJ6.2C-T2 Z DIODE I/M
D 218 1SS133-T2 SI DIODE IM
D 219 11ES2-T4 DIODE I.M
D 220 11ES2-T4 DIODE I.M
Item
Parts number Parts name Ar
e
a
Remarks
A
