JVC RX-5020VBK Service Manual

3-9
RX-5020VBK/RX-5022VSL
Item
Parts number Parts name Ar
e
a
Remarks
A
C 400 QCBB1HK-223Y C CAPACITOR .022MF 10% 50V
C 419 QCBB1HK-223Y C CAPACITOR .022MF 10% 50V
C 420 QCBB1HK-223Y C CAPACITOR .022MF 10% 50V
C 421 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 422 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 423 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 424 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 425 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 426 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 427 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 428 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 429 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 430 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 431 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 432 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 433 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 434 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 435 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 436 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 440 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 441 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 442 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 443 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 444 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 445 QCBB1HK-223Y C CAPACITOR .022MF 10% 50V
C 446 QCBB1HK-223Y C CAPACITOR .022MF 10% 50V
C 451 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 452 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 459 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V
C 460 QCZ0202-155Z ML C CAPA I/M 1.5MF
CN311 QGB2510J1-14 CONNECTOR
CN312 QGB2510J1-14 CONNECTOR
CN321 QGB2510J1-14 CONNECTOR
CN331 QGB2510J1-14 CONNECTOR
CN332 QGB2510J1-14 CONNECTOR
CN351 QJK012-032403 SKT WIRE ASSY
CN371 QJP001-031201 SHI CR C-B WIRE
CN372 QJP002-021201 SHI CR C-B WIRE
CN373 QJP001-031201 SHI CR C-B WIRE
CN401 QGB2510K1-14 CONNECTOR
CN451 QGB2510K1-11 CONNECTOR
C1301 QFZ9076-104Z MM CAPACITOR .10MF
C1302 QCE22HP-103 C CAPACITOR .010MF +100:-0%
C1303 QCE22HP-103 C CAPACITOR .010MF +100:-0%
C1304 QEZ0341-688 E CAPACITER 6800MF
C1305 QEZ0341-688 E CAPACITER 6800MF
C1306 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C1308 QETN1HM-476Z E CAPACITOR 47MF 20% 50V
C1309 QEKC1HM-106Z E CAPACITOR 10MF 20% 50V
C1310 QEKC1CM-476Z E CAPACITOR 47MF 20% 16V
C1311 QEKC1HM-226Z E CAPACITOR 22MF 20% 50V
C1351 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1352 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1353 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1354 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
D1301 30DF2-FC DIODE
A
D1302 30DF2-FC DIODE
A
D1303 30DF2-FC DIODE
A
D1304 30DF2-FC DIODE
A
D1305 MTZJ18C-T2 Z.DIODE I.M
D1306 MTZJ30C-T2 ZENER DIODE
D1307 1SS133-T2 SI DIODE IM
D1308 1SS133-T2 SI DIODE IM
D1309 MTZJ20C-T2 Z.DIODE I.M
D1352 1SS133-T2 SI DIODE IM
D1353 1SS133-T2 SI DIODE IM
D1354 1SS133-T2 SI DIODE IM
D1355 1SS133-T2 SI DIODE IM
D1356 MTZJ5.1C-T2 ZENER DIODE
D1357 1SS133-T2 SI DIODE IM
D1358 1SS133-T2 SI DIODE IM
D1359 1SS133-T2 SI DIODE IM
D1360 1SS133-T2 SI DIODE IM
EP301 QNZ0136-001Z EARTH PLATE
FW301 QUM135-25Z4Z4 PARA RIBON WIRE
FW302 QUM136-25Z4Z4 PARA RIBON WIRE
FW303 QUM135-28DGZ4 PARA RIBON WIRE
FW341 QUM135-20DGZ4 PARA RIBON WIRE
IC402 TC9164AN IC
IC403 BA15218N IC
J 402 QNN0168-001 PIN JACK
J 403 QNN0168-001 PIN JACK
J 404 QNN0389-001 PIN JACK DVD FL/FR
J 406 QNN0060-001 PIN JACK
Q
1301 KTA1046/Y/ TRANSISTOR
A
Q
1302 KTC3200/GL/-T TRANSISTOR
Q
1303 KTA1268/GL/-T TRANSISTOR
Q
1304 KTC3199/GL/-T TRANSISTOR
Q
1305 2SD2395/EF/ TRANSISTOR
Q
1306 KTA1023/OY/-T TRANSISTOR
Q
1307 KTC3200/GL/-T TRANSISTOR
Q
1351 KRC109M-T D.TR.I.M.
Q
1352 KRC109M-T D.TR.I.M.
Q
1353 KRC109M-T D.TR.I.M.
Q
1354 KRC109M-T D.TR.I.M.
Q
1355 KRC109M-T D.TR.I.M.
Q
1356 KRC109M-T D.TR.I.M.
Q
1357 KRC109M-T D.TR.I.M.
Q
1358 KRC109M-T D.TR.I.M.
R 421 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 422 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 423 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 424 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 425 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 426 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 429 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 430 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 431 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 432 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 435 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 436 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 440 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 441 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 442 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 443 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 444 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 445 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 446 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 449 QRJ146J-271X UNF C RESISTOR
A
270 5% 1/4W
R 450 QRJ146J-271X UNF C RESISTOR
A
270 5% 1/4W
R 451 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 452 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 458 QRJ146J-271X UNF C RESISTOR 270 5% 1/4W
R 459 QRJ146J-271X UNF C RESISTOR 270 5% 1/4W
RY302 QSK0109-001 RELAY
A
RY303 QSK0109-001 RELAY
A
Electrical parts list (Main board)
Block No. 02
Item
Parts number Parts name
Are
a
Remarks
A
