JVC RX-5020VBK Service Manual

3-10
RX-5020VBK/RX-5022VSL
Item
Parts number Parts name Ar
e
a
Electrical parts list (Main board)
Remarks
Block No. 02
A
RY304 QSK0109-001 RELAY
A
R1301 QRL027J-332 UNF OMF RESISTO
A
3.3K 5% 1/2W
R1302 QRZ9005-100X F RESISTOR
A
10 1/4W
R1303 QRJ146J-562X UNF C RESISTOR
A
5.6K 5% 1/4W
R1304 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1305 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1306 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R1307 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1308 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1309 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1310 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1311 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1312 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1313 QRZ9005-100X F RESISTOR
A
10 1/4W
R1314 QRJ146J-103X UNF C RESISTOR
A
10K 5% 1/4W
R1315 QRJ146J-2R2X UNF C RESISTOR
A
2.2 5% 1/4W
R1316 QRJ146J-102X UNF C RESISTOR
A
1.0K 5% 1/4W
R1317 QRJ146J-223X UNF C RESISTOR
A
22K 5% 1/4W
R1318 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1319 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R1352 QRJ146J-680X UNF C RESISTOR
A
68 5% 1/4W
R1353 QRJ146J-680X UNF C RESISTOR
A
68 5% 1/4W
R1354 QRJ146J-680X UNF C RESISTOR
A
68 5% 1/4W
R1355 QRJ146J-392X UNF C RESISTOR
A
3.9K 5% 1/4W
R1356 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1357 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1358 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R1359 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1360 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1361 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1362 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1363 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1364 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1365 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R1366 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1367 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
ST304 QNB0103-002 SPK TERMINAL 6010 CENT/REAR
ST305 QNB0001-002 SPK TERMINAL 5020/6020 FRONT
