JVC RX-5020VBK Service Manual

3-11
RX-5020VBK/RX-5022VSL
Item
Parts number Parts name Ar
e
a
Remarks
A
BK701 LV42093-001A FL HOLDER(L)
BK702 LV42092-001A FL HOLDER(R)
C 701 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 702 QCZ0202-155Z ML C CAPA I/M 1.5MF
C 703 QEKC1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 704 NCB31CK-223X C CAPACITOR
C 705 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 706 NCB21HK-331X C.CAPA. C.M
C 707 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 708 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 709 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 713 NCB21HK-103X C CAPACITOR
C 714 NCB21HK-103X C CAPACITOR
C 715 NCB21HK-103X C CAPACITOR
C 716 NCB21HK-103X C CAPACITOR
C 717 NCB21HK-103X C CAPACITOR
C 718 NCB21HK-103X C CAPACITOR
C 719 NCB21HK-103X C CAPACITOR
C 720 NCB31CK-104X C CAPACITOR
C 721 NCB31CK-104X C CAPACITOR
C 722 QCZ0202-155Z ML C CAPA I/M 1.5MF
C 730 NCB31CK-104X C CAPACITOR
CN402 QGF1205C1-25 CONNECTOR
CN411 QGB2501J1-12 CONNECTOR
CN421 QGB2510J1-14 CONNECTOR
CN431 QGB2510J1-11 CONNECTOR
CN441 QGB2510J1-07 CONNECTOR
CN471 QGA2501C1-03 3P CONNECTOR
CN472 QGA2501C1-02 2P CONNECTOR
CN473 QGA2501C1-03 3P CONNECTOR
CN481 QGB2510J1-20 CONNECTOR
CN491 QGB2510J1-04 CONNECTOR
CN701 QGF1205F1-14 CONNECTOR
CN702 QGF1205F1-25 CONNECTOR
CN704 WJS0020-001A SKT.WIRE ASS'Y
CN714 QGA2001C1-03 3P PLUG ASSY
C1401 QETN1HM-476Z E CAPACITOR 47MF 20% 50V
C1402 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C1403 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C1404 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C1405 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C1406 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C1407 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C1408 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C1409 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C1410 NCB31CK-223X C CAPACITOR
C1411 NCB31CK-223X C CAPACITOR
C1422 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1423 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1424 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1425 QEKC1CM-106Z E CAPACITOR 10MF 20% 16V
C1426 NCB31CK-223X C CAPACITOR
C1427 QFVF1HJ-334Z MF CAPACITOR .33MF 5% 50V
C1428 QFLC1HJ-153Z M CAPACITOR .015MF 5% 50V
C1429 QCB31HK-822Z C CAPACITOR 8200PF 10% 50V
C1430 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1431 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1432 NCB31CK-223X C CAPACITOR
C1433 QFVF1HJ-334Z MF CAPACITOR .33MF 5% 50V
C1434 QFLC1HJ-153Z M CAPACITOR .015MF 5% 50V
C1435 QCB31HK-822Z C CAPACITOR 8200PF 10% 50V
C1436 NCB31CK-223X C CAPACITOR
C1437 QCZ0202-155Z ML C CAPA I/M 1.5MF
C1438 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C1439 QFLC1HJ-562Z M CAPACITOR 5600PF 5% 50V
C1440 QFLC1HJ-562Z M CAPACITOR 5600PF 5% 50V
C1443 QCZ0202-155Z ML C CAPA I/M 1.5MF
C1444 NCB31CK-223X C CAPACITOR
C1445 NCB31CK-223X C CAPACITOR
C1446 NCB31HK-221X C CAPACITOR
C1447 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1453 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1459 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1460 NCB31CK-223X C CAPACITOR
C1461 NCB31CK-223X C CAPACITOR
C1463 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1464 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1465 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
D 701 1SS355-X DIODE C.M
D 702 1SS355-X DIODE C.M
D 719 SLR-342VC-T LED
DI701 QLF0098-001 FL TUBE
D1401 MTZJ13C-T2 ZENER DIODE
D1402 MTZJ6.2C-T2 Z DIODE I/M
D1403 MTZJ5.6C-T2 ZENER DIODE
D1404 MTZJ5.6C-T2 ZENER DIODE
D1405 MTZJ13C-T2 ZENER DIODE
D1406 MTZJ10C-T2 Z.DIODE I.M
D1407 MTZJ7.5C-T2 ZENER DIODE
D1408 MTZJ7.5C-T2 ZENER DIODE
D1409 1SS355-X DIODE C.M
D1410 1SS355-X DIODE C.M
D1411 1SS355-X DIODE C.M
D1412 1SS355-X DIODE C.M
EP401 QNZ0136-001Z EARTH PLATE
FL401 QQR0590-001 FILTER
FL402 QQR0590-001 FILTER
HS401 E70306-001 HEAT SINK
HS402 E70306-001 HEAT SINK
HS403 E70306-001 HEAT SINK
HS404 E70306-001 HEAT SINK
HS405 E70306-001 HEAT SINK
HS434 E70306-001 HEAT SINK
HS435 E70306-001 HEAT SINK
IC423 TC9162AF-X IC
IC427 BA15218F-XE IC
IC428 M62446FP-X IC
IC701 MN101C35DJW IC
IC702 IC-PST9139-T IC I.M
IC703 GP1UM281XK IR DETECT UNIT
JS701 QSW0898-001 JOG VOLUME
Q
701 DTC114YKA-X CHIP D.TRANSIST
Q
702 DTC114TKA-X TRANSISTOR
Q
703 DTC144WKA-X TRANSISTOR
Q
704 DTC114YKA-X CHIP D.TRANSIST
Q
707 DTC114YKA-X CHIP D.TRANSIST
Q
708 DTC114YKA-X CHIP D.TRANSIST
Q
709 DTC114YKA-X CHIP D.TRANSIST
Q
711 DTA144EKA-X TRANSISTOR
Q
1401 KTA1046/Y/ TRANSISTOR
A
Q
1402 2SD2395/EF/ TRANSISTOR
A
Q
1403 2SD2395/EF/ TRANSISTOR
A
Q
1404 2SD2395/EF/ TRANSISTOR
A
Q
1405 2SD2395/EF/ TRANSISTOR
A
Q
1406 KTC3203/OY/-T TRANSISTOR
A
Q
1407 KTC3203/OY/-T TRANSISTOR
A
Electrical parts list (System control & Audio board)
Block No. 03
Item
Parts number Parts name
Are
a
Remarks
A
