JVC RX-5020VBK Service Manual

3-12
RX-5020VBK/RX-5022VSL
Item
Parts number Parts name Ar
e
a
Remarks
A
Q
1408 KTA1271/OY/-T TRANSISTOR
A
Q
1413 2SC3576-JVC-T TRANSISTOR I/M
Q
1414 2SC3576-JVC-T TRANSISTOR I/M
Q
1417 2SC3576-JVC-T TRANSISTOR I/M
Q
1418 2SC3576-JVC-T TRANSISTOR I/M
Q
1419 2SC3576-JVC-T TRANSISTOR I/M
Q
1420 KRA104M-T D.TR.I.M
Q
1421 2SC3576-JVC-T TRANSISTOR I/M
Q
1422 2SC3576-JVC-T TRANSISTOR I/M
Q
1423 KRA104M-T D.TR.I.M
Q
1424 KRA104M-T D.TR.I.M
Q
1425 2SC3576-JVC-T TRANSISTOR I/M
Q
1426 2SC3576-JVC-T TRANSISTOR I/M
Q
1431 KRC104M-T D.TR.I.M
Q
1432 KRC104M-T D.TR.I.M
Q
1433 KRC104M-T D.TR.I.M
Q
1434 2SD2395/EF/ TRANSISTOR
A
Q
1435 2SD2395/EF/ TRANSISTOR
A
R 475 NRSA63J-203X MG RESISTOR
R 476 NRSA63J-273X MG RESISTOR
R 477 QRZ9006-4R7X F RESISTOR 4.7 1/4W
R 478 QRJ146J-2R2X UNF C RESISTOR 2.2 5% 1/4W
R 479 QRJ146J-2R2X UNF C RESISTOR 2.2 5% 1/4W
R 480 NRSA63J-512X MG RESISTOR
R 481 NRSA63J-104X MG RESISTOR
R 482 NRSA63J-104X MG RESISTOR
R 483 NRSA63J-102X MG RESISTOR
R 484 NRSA63J-104X MG RESISTOR
R 485 NRSA63J-102X MG RESISTOR
R 486 NRSA63J-104X MG RESISTOR
R 487 NRSA63J-102X MG RESISTOR
R 488 NRSA63J-104X MG RESISTOR
R 489 NRSA63J-103X MG RESISTOR
R 490 NRSA63J-103X MG RESISTOR
R 491 NRSA63J-512X MG RESISTOR
R 492 NRSA63J-0R0X MG RESISTOR
R 493 NRSA63J-0R0X MG RESISTOR
R 494 NRSA63J-0R0X MG RESISTOR
R 495 NRSA63J-0R0X MG RESISTOR
R 701 NRSA63J-472X MG RESISTOR
R 702 NRSA63J-223X MG RESISTOR
R 703 NRSA63J-103X MG RESISTOR
R 704 NRSA63J-471X MG RESISTOR
R 705 NRSA63J-103X MG RESISTOR
R 706 NRSA63J-103X MG RESISTOR
R 707 NRSA63J-103X MG RESISTOR
R 708 NRSA63J-103X MG RESISTOR
R 709 NRSA63J-103X MG RESISTOR
R 710 NRSA63J-103X MG RESISTOR
R 711 NRSA63J-104X MG RESISTOR
R 712 NRSA63J-103X MG RESISTOR
R 713 NRSA63J-103X MG RESISTOR
R 714 NRSA63J-103X MG RESISTOR
R 715 NRSA63J-103X MG RESISTOR
R 716 NRSA63J-103X MG RESISTOR
R 717 NRSA63J-103X MG RESISTOR
R 718 NRSA63J-103X MG RESISTOR
R 719 NRSA63J-221X MG RESISTOR
R 720 NRSA63J-222X MG RESISTOR
R 721 NRSA63J-103X MG RESISTOR
R 722 NRSA63J-102X MG RESISTOR
R 723 NRSA63J-102X MG RESISTOR
R 724 NRSA63J-122X MG RESISTOR
R 725 NRSA63J-152X MG RESISTOR
R 726 NRSA63J-222X MG RESISTOR
R 727 NRSA63J-272X MG RESISTOR
R 728 NRSA63J-103X MG RESISTOR
R 729 NRSA63J-102X MG RESISTOR
R 730 NRSA63J-102X MG RESISTOR
R 731 NRSA63J-122X MG RESISTOR
R 732 NRSA63J-152X MG RESISTOR
R 733 NRSA63J-222X MG RESISTOR
R 734 NRSA63J-272X MG RESISTOR
R 736 NRSA63J-103X MG RESISTOR
R 737 NRSA63J-102X MG RESISTOR
R 738 NRSA63J-102X MG RESISTOR
R 739 NRSA63J-122X MG RESISTOR
R 740 NRSA63J-152X MG RESISTOR
R 741 NRSA63J-222X MG RESISTOR
R 742 NRSA63J-272X MG RESISTOR
R 743 NRSA63J-103X MG RESISTOR
R 744 NRSA63J-102X MG RESISTOR
R 745 NRSA63J-102X MG RESISTOR
R 746 NRSA63J-122X MG RESISTOR
R 747 NRSA63J-152X MG RESISTOR
R 748 NRSA63J-222X MG RESISTOR
R 749 NRSA63J-272X MG RESISTOR
R 750 NRSA63J-103X MG RESISTOR
R 757 NRSA63J-103X MG RESISTOR
R 758 NRSA63J-103X MG RESISTOR
R 759 NRSA63J-103X MG RESISTOR
R 760 NRSA63J-103X MG RESISTOR
R 761 NRSA63J-103X MG RESISTOR
R 762 NRSA63J-102X MG RESISTOR
R 768 NRSA63J-103X MG RESISTOR
R 769 NRSA63J-102X MG RESISTOR
R 772 NRSA63J-392X MG RESISTOR
R 773 NRSA63J-392X MG RESISTOR
R 775 NRSA63J-103X MG RESISTOR
R 779 NRSA63J-103X MG RESISTOR
R 783 NRSA63J-221X MG RESISTOR
R 784 NRSA63J-221X MG RESISTOR
R 785 NRSA63J-221X MG RESISTOR
R 786 NRSA63J-221X MG RESISTOR
R 787 NRSA63J-221X MG RESISTOR
R 788 NRSA63J-221X MG RESISTOR
R 789 NRSA63J-221X MG RESISTOR
R 790 NRSA63J-221X MG RESISTOR
R 791 NRSA63J-221X MG RESISTOR
R 792 NRSA63J-221X MG RESISTOR
R 793 NRSA63J-221X MG RESISTOR
R 794 NRSA63J-221X MG RESISTOR
R 795 NRSA63J-221X MG RESISTOR
R 796 NRSA63J-221X MG RESISTOR
R 797 NRSA63J-221X MG RESISTOR
R 798 NRSA63J-221X MG RESISTOR
R 799 NRSA63J-221X MG RESISTOR
R 871 NRSA63J-103X MG RESISTOR
R 872 NRSA63J-103X MG RESISTOR
R 873 NRSA63J-103X MG RESISTOR
R1401 QRZ9005-100X F RESISTOR
A
10 1/4W
R1402 QRJ146J-182X UNF C RESISTOR
A
1.8K 5% 1/4W
R1403 QRZ9005-120X F RESISTOR
A
12 1/4W
R1404 QRJ146J-272X UNF C RESISTOR
A
2.7K 5% 1/4W
R1405 QRZ9005-120X F RESISTOR
A
12 1/4W
R1406 QRK126J-682X C RESISTOR
A
6.8K 5% 1/2W
Electrical parts list (System control & Audio board)
Block No. 03
Item
Parts number Parts name Ar
e
a
Remarks
A
