JVC RX-5020VBK Service Manual

3-7
RX-5020VBK/RX-5022VSL
Item
Parts number Parts name Ar
e
a
Remarks
A
R 316 QRJ146J-331X UNF C RESISTOR
A
330 5% 1/4W
R 317 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 318 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 319 QRJ146J-331X UNF C RESISTOR 330 5% 1/4W
R 320 QRJ146J-331X UNF C RESISTOR 330 5% 1/4W
R 321 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 322 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 323 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 324 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 325 QRE141J-361Y C RESISTOR 360 5% 1/4W
R 326 QRE141J-361Y C RESISTOR 360 5% 1/4W
R 327 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 328 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 329 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 330 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 331 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 332 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 333 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 334 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 335 QRE141J-121Y C RESISTOR 120 5% 1/4W
R 336 QRE141J-121Y C RESISTOR 120 5% 1/4W
R 337 QRE141J-121Y C RESISTOR 120 5% 1/4W
R 338 QRE141J-121Y C RESISTOR 120 5% 1/4W
R 339 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 340 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 341 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 342 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 343 QRZ0218-R22 C RESISTOR 1/2W
R 344 QRZ0218-R22 C RESISTOR 1/2W
R 345 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 346 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 347 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R 348 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R 349 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 350 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 351 QRJ125J-330 UNF OMF RESISTO
A
33 5% 1/2W
R 352 QRJ125J-330 UNF OMF RESISTO
A
33 5% 1/2W
R 353 QRL027J-100 UNF OMF RESISTO
A
10 5% 1/2W
R 354 QRL027J-100 UNF OMF RESISTO
A
10 5% 1/2W
R 363 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 364 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 501 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 502 QRE141J-750Y C RESISTOR 75 5% 1/4W
R 505 QRE141J-750Y C RESISTOR 75 5% 1/4W
R 506 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 507 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 508 QRE141J-750Y C RESISTOR 75 5% 1/4W
R 509 QRE141J-750Y C RESISTOR 75 5% 1/4W
R 510 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 511 QRE141J-151Y C RESISTOR 150 5% 1/4W
R 512 QRE141J-271Y C RESISTOR 270 5% 1/4W
R 513 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R 514 QRE141J-151Y C RESISTOR 150 5% 1/4W
R 515 QRE141J-271Y C RESISTOR 270 5% 1/4W
R 516 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R 521 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 522 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 801 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 802 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 803 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 804 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 805 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R 806 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R 807 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 808 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 809 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 810 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 811 QRJ146J-391X UNF C RESISTOR 390 5% 1/4W
R 812 QRJ146J-391X UNF C RESISTOR 390 5% 1/4W
R 813 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 814 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 815 QRJ146J-331X UNF C RESISTOR
A
330 5% 1/4W
R 816 QRJ146J-331X UNF C RESISTOR
A
330 5% 1/4W
R 821 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 822 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 823 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 824 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 825 QRE141J-361Y C RESISTOR 360 5% 1/4W
R 826 QRE141J-361Y C RESISTOR 360 5% 1/4W
R 827 QRE141J-821Y C RESISTOR 820 5% 1/4W
R 828 QRE141J-821Y C RESISTOR 820 5% 1/4W
R 829 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 830 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 831 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 832 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 833 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 834 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 835 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 836 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 837 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 838 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 839 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 840 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 841 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 842 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 843 QRZ0218-R22 C RESISTOR 1/2W
R 844 QRZ0218-R22 C RESISTOR 1/2W
R 845 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 846 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 847 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R 848 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R 849 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R 850 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R 851 QRJ125J-330 UNF OMF RESISTO
A
33 5% 1/2W
R 852 QRJ125J-330 UNF OMF RESISTO
A
33 5% 1/2W
R 853 QRL027J-100 UNF OMF RESISTO
A
10 5% 1/2W
R 854 QRL027J-100 UNF OMF RESISTO
A
10 5% 1/2W
R 855 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 856 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 857 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 858 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 859 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 860 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 861 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 862 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 863 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 864 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 901 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 903 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 905 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R 907 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 909 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 911 QRJ146J-301X UNF C RESISTOR 300 5% 1/4W
R 913 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 915 QRJ146J-331X UNF C RESISTOR
A
330 5% 1/4W
R 921 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
Electrical parts list (Power amp board)
Block No. 01
Item
Parts number Parts name Ar
e
a
Remarks
A
