6
VIDEO
VCR
OUT
(REC)
IN
(PLAY)
MONITOR
OUT
DVD
IN
(PLAY)
CD
OUT
(REC)
AUDIO
RIGHT LEFT
TV SOUND
OUT
(REC)
VCR
TAPE
CDR
IN
(PLAY)
CD
PHONO
AUDIO
TV SOUND
IN
(PLAY)
CD
IN
(PLAY)
RIGHT LEFT
TAPE
CDR
OUT
(REC)
VCR
OUT
(REC)
Getting Started
Video component connections
Use the cables with RCA pin plugs (not supplied).
Connect the white plug to the audio left jack, the red plug to the
audio right jack, and the yellow plug to the video jack.
Connecting Audio/Video Components
Turn off all components before connecting.
Analog connections
Audio component connections
Use the cables with RCA pin plugs (not supplied).
Connect the white plug to the audio left jack, and the red plug to the
audio right jack.
CAUTION:
If you connect a sound-enhancing device such as a graphic equalizer
between the source components and this receiver, the sound output
through this receiver may be distorted.
To audio output
CD player
Cassette deck or CD recorder
To audio output
CD recorder
To audio outputTo audio input
TAPE
CDR
CD
OUT
(REC)
IN
(PLAY)
Note:
You can connect either a cassette deck or a CD recorder to the TAPE/
CDR jacks. When connecting a CD recorder to the TAPE/CDR jacks,
change the source name to “CDR”, which will be shown on the display
when selected as the source. See page 9 for details.
If your audio components have a COMPU LINK jack
See also page 25 for detailed information about the connection and
the COMPU LINK remote control system.
TV
To audio
output
Connect the TV to the MONITOR OUT jack to view
the playback picture from the other connected video
components.
To video input
TV
VCR
Å To left/right channel audio output
ı To left/right channel audio input
Ç To video output
Î To video input
VCR
A
VIDEO
TV SOUND
VCR
OUT
(REC)
OUT
(REC)
IN
(PLAY)
IN
(PLAY)
TAPE
CDR
CD
OUT
(REC)
IN
(PLAY)
MONITOR
OUT
RIGHT LEFT
DVD
AUDIO
C
D
B
VCR
CD player
Cassette deck
To audio input
EN01-07.RX-6020V[J]_f 01.12.7, 11:32 AM6
