JVC RX-7030VBK Service Manual

1-2 (No.MB003)
SPECIFICATION
Amplifier Output Power At Stereo operation Front ch 100 W per channel, min. RMS,
driven into 8 Ω at 1 kHz, with no
more than 0.8% total harmonic
distortion (IEC268-3/DIN).
At Surround operation Front ch 100 W per channel, min. RMS,
driven into 8 Ω at 1 kHz, with no
more than 0.8% total harmonic
distortion.
Center ch 100 W, min. RMS, driven into 8 Ω
at 1 kHz, with no more than 0.8%
total harmonic distortion.
Surround ch 100 W per channel, min. RMS,
driven into 8 Ω at 1 kHz, with no
more than 0.8% total harmonic
distortion.
Surround Back ch 100 W, min. RMS, driven into 8 Ω
at 1 kHz, with no more than 0.8%
total harmonic distortion.
Audio Audio Input Sensitivity/
Impedance (1 kHz)
DVD IN, VCR IN, TV SOUND/DBS IN 200 mV/47 kΩ
CD IN, TAPE/CDR IN 200 mV/47 kΩ
Audio Input
(DIGITAL IN)*
Coaxial DIGITAL 1 (DVD) 0.5 V(p-p)/75 Ω
Optical DIGITAL 2 (CD),
DIGITAL 3 (TV),
DIGITAL 4 (CDR)
-21 dBm to -15 dBm
(660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround (with sampling frequency-32 kHz, 44.1 kHz,
48 kHz).
Audio Output Level SUBWOOFER OUT 1 V
Recording Output Level VCR OUT, TAPE/CDR OUT 200 mV
Digital output Optical DIGITAL OUT
Signal wave length 660 nm
Output level -21 dBm to -15 dBm
Signal-to-Noise Ratio
(‘66 IHF/DIN)
DVD IN, VCR IN, TV SOUND/DBS IN 87 dB/67 dB
CD IN, TAPE/CDR IN 87 dB/67 dB
Frequency
Response
(8 Ω)
DVD IN, VCR IN, TV SOUND/DBS IN 20 Hz to 100 kHz (+1 dB, -3 dB)
CD IN, TAPE/CDR IN 20 Hz to 100 kHz (+1 dB, -3 dB)
Equalization (5 bands) 63 Hz, 250 Hz, 1 kHz, 4 kHz,
16 kHz (±8 dB)
Bass boost +6 dB ±1.0 dB at 100 Hz
Video Video Input Sensitivity
/Impedance
Composite
video
DVD IN, VCR IN, TV SOUND/DBS IN: 1 V(p-p)/75 Ω
S-video DVD IN, VCR IN,
TV SOUND/DBS IN
(Y: luminance) 1 V(p-p)/75 Ω
(C: chrominance, burst) 0.286 V(p-p)/75 Ω
Video Output Level Composite
video
VCR OUT,
MONITOR OUT
1 V(p-p)/75 Ω
S-video VCR OUT,
MONITOR OUT
(Y: luminance) 1 V(p-p)/75 Ω
(C: chrominance, burst) 0.286 V(p-p)/75 Ω
Synchronization Negative
Signal-to-Noise Ratio 45 dB
