JVC RX-7030VBK Service Manual

3-6
Front board
Block No. [0][2][0][0]
CN703 QGB2510J1-10 CONNECTOR B-B (1-10)
CN704 QGB2510J1-10 CONNECTOR B-B (1-10)
CN705 QGB2510J1-12 CONNECTOR B-B (1-12)
CN706 QGB2510J1-12 CONNECTOR B-B (1-12)
CN723 QGA2501C1-04 CONNECTOR W-B (1-4)
CN801 QJK012-032403 SKT WIRE ASSY
CN813 QGA3901C1-06 CONNECTOR W-B (1-6)
CN814 QGA3901C1-07 CONNECTOR W-B (1-7)
CN823 QJK015-063001 C-B WIRE ASSY
CN824 QJK015-073202 SKT WIRE ASSY
CN831 QGD2501C1-04Z CONNECTOR (1-4)
CN881 QGD2501C1-03Z CONNECTOR (1-3)
EP801 QNZ0136-001Z EARTH PLATE
FW931 QUM217-08DGZ4 PARA RIBON WIRE
RY831 QSK0109-001 RELAY
RY832 QSK0109-001 RELAY
RY851 QSK0149-001 RELAY
RY852 QSK0109-001 RELAY
RY853 QSK0149-001 RELAY
RY871 QSK0109-001 RELAY
ST832 QNB0082-002 SPK TERMINAL
ST833 QNB0079-001 SPK TERMINAL
ST853 QNB0111-001 SPK.TERMINAL
 Symbol No. Part No. Part Name Description Local
PW401 QUB030-17PPHM SIN TWIST WIRE
PW402 QUB131-18PPDM CONNECTOR
IC201 BA7625 IC Video selector
IC241 BA7626 IC Video selector
IC242 BA7625 IC Video selector
IC303 HA17558AF-X IC Ope. amp.
IC371 TC9163AF-X IC
IC372 SAA6588 IC(RDS)
RDS Detector (only
CA-MXS5RMD)
IC400 MN101C35DMF IC
System control &
FL driver
IC404 GP1UM281XK IR DETECT UNIT
Dual operation
amplifier
Q200 KTA1267/YG/-T TRANSISTOR
Q204 KTA1267/YG/-T TRANSISTOR
Q240 KTA1267/YG/-T TRANSISTOR
Q241 KTA1267/YG/-T TRANSISTOR
Q244 KTA1267/YG/-T TRANSISTOR
Q254 KTA1267/YG/-T TRANSISTOR
Q301 2SC3576-JVC-T TRANSISTOR
Q302 2SC3576-JVC-T TRANSISTOR
Q303 KRA104S-X DIGI TRANSISTOR
Q402 UN2215-X TRANSISTOR
Q403 KRC109S-X TRANSISTOR
Q404 KRC107S-X DIGI TRANSISTOR
Q407 KRC107S-X DIGI TRANSISTOR
Q408 KRC107S-X DIGI TRANSISTOR
Q410 UN2114-X TRANSISTOR
Q411 UN2114-X TRANSISTOR
Q413 UN2114-X TRANSISTOR
D405 1SS133-T2 DIODE
D480 SLR-343VC/NPQ-T LED
D490 SLR-343VC/NPQ-T LED
D491 SLR-343VC/NPQ-T LED
C201 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C202 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C203 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C204 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C207 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C208 QETN1CM-476Z E CAPACITOR 47uF 16V M
C209 QCF31HZ-103Z C CAPACITOR 0.01uF 50V Z
C211 QETN1CM-476Z E CAPACITOR 47uF 16V M
 Symbol No. Part No. Part Name Description Local
C212 QCF31HZ-103Z C CAPACITOR 0.01uF 50V Z
C226 NCS31HJ-470X C CAPACITOR 47pF 50V J
C228 NCS31HJ-470X C CAPACITOR 47pF 50V J
C241 QDX31EM-473Z C CAPACITOR 0.047uF 25V M
C242 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C243 QCF31HZ-103Z C CAPACITOR 0.01uF 50V Z
C244 QDX31EM-473Z C CAPACITOR 0.047uF 25V M
C245 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C246 QDX31EM-473Z C CAPACITOR 0.047uF 25V M
C247 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C248 QETN1CM-476Z E CAPACITOR 47uF 16V M
C249 QDX31EM-473Z C CAPACITOR 0.047uF 25V M
C250 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C251 QDX31EM-473Z C CAPACITOR 0.047uF 25V M
C252 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C256 QCF31HZ-103Z C CAPACITOR 0.01uF 50V Z
C257 QETN1CM-476Z E CAPACITOR 47uF 16V M
C258 QCF31HZ-103Z C CAPACITOR 0.01uF 50V Z
C259 QETN1CM-476Z E CAPACITOR 47uF 16V M
C268 NCS31HJ-470X C CAPACITOR 47pF 50V J
C269 NCS31HJ-470X C CAPACITOR 47pF 50V J
C270 NCS31HJ-470X C CAPACITOR 47pF 50V J
C271 NCS31HJ-470X C CAPACITOR 47pF 50V J
C280 NCS31HJ-470X C CAPACITOR 47pF 50V J
C281 NCS31HJ-470X C CAPACITOR 47pF 50V J
C282 NCS31HJ-470X C CAPACITOR 47pF 50V J
C283 NCS31HJ-470X C CAPACITOR 47pF 50V J
C284 NCS31HJ-470X C CAPACITOR 47pF 50V J
C285 NCS31HJ-470X C CAPACITOR 47pF 50V J
C317 NCB31HK-221X C CAPACITOR 220pF 50V K
C318 NCB31HK-221X C CAPACITOR 220pF 50V K
C341 QETN1CM-106Z E CAPACITOR 10uF 16V M
C342 QETN1CM-106Z E CAPACITOR 10uF 16V M
C343 QETN1CM-106Z E CAPACITOR 10uF 16V M
C344 QETN1CM-106Z E CAPACITOR 10uF 16V M
C351 QFLC1HJ-562Z M CAPACITOR 5600pF 50V J
C352 QFLC1HJ-562Z M CAPACITOR 5600pF 50V J
C371 NCB31HK-221X C CAPACITOR 220pF 50V K
C372 NCB31HK-221X C CAPACITOR 220pF 50V K
C373 NCB31HK-221X C CAPACITOR 220pF 50V K
C374 NCB31HK-221X C CAPACITOR 220pF 50V K
C375 NCB31HK-331X C CAPACITOR 330pF 50V K
C376 NCB31HK-331X C CAPACITOR 330pF 50V K
C377 NCB31HK-221X C CAPACITOR 220pF 50V K
C378 NCB31HK-221X C CAPACITOR 220pF 50V K
C379 NCB31HK-331X C CAPACITOR 330pF 50V K
C380 NCB31HK-331X C CAPACITOR 330pF 50V K
C381 NCB31HK-221X C CAPACITOR 220pF 50V K
C382 NCB31HK-221X C CAPACITOR 220pF 50V K
C385 QETN1EM-226Z E CAPACITOR 22uF 25V M
C386 QETN1EM-226Z E CAPACITOR 22uF 25V M
C389 NCB31HK-561X C CAPACITOR 560pF 50V K
C391 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C392 NCS31HJ-470X C CAPACITOR 47pF 50V J
C393 NCS31HJ-470X C CAPACITOR 47pF 50V J
C394 QDX31EM-473Z C CAPACITOR 0.047uF 25V M
C395 QETN1CM-106Z E CAPACITOR 10uF 16V M
C396 NCB31HK-561X C CAPACITOR 560pF 50V K
C397 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C398 NCS31HJ-331X C CAPACITOR 330pF 50V J
C399 QETN1CM-226Z E CAPACITOR 22uF 16V M
C400 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C401 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C402 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C403 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C404 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C406 NCB31HK-331X C CAPACITOR 330pF 50V K
C407 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C409 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C410 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C411 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C412 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C413 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C414 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C420 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C421 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C422 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C423 NCB31HK-103X C CAPACITOR 0.01uF 50V K
 Symbol No. Part No. Part Name Description Local
