JVC RX-7030VBK Service Manual

3-9
Power board
Block No. [0][4][0][0]
C975 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C981 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C982 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C983 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C984 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C985 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C993 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C994 QCBB1HK-271Y C CAPACITOR 270pF 50V K
 R53 QRJ146J-6R8X UNF C RESISTOR 6.8 Ω 1/4W J
R54 QRE141J-821Y C RESISTOR 820 Ω 1/4W J
R61 QRJ146J-8R2X UNF C RESISTOR 8.2 Ω 1/4W J
R72 QRJ146J-332X UNF C RESISTOR 3.3k Ω 1/4W J
R73 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R74 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R91 QRL027J-471 OMF RESISTOR 470 Ω 2W J
R92 QRL027J-471 OMF RESISTOR 470 Ω 2W J
R903 QRE141J-331Y C RESISTOR 330 Ω 1/4W J
R904 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R910 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R911 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R913 QRT027J-3R9 MF RESISTOR 3.9
Ω 2W J
R914 QRL027J-160 OMF RESISTOR 16 Ω 2W J
R915 QRT027J-3R9 MF RESISTOR 3.9 Ω 2W J
R916 QRL027J-100 OMF RESISTOR 10 Ω 2W J
R918 QRL027J-100 OMF RESISTOR 10 Ω 2W J
R921 QRK126J-120X UNF C RESISTOR 12 Ω 1/2W J
R923 QRJ146J-272X UNF C RESISTOR 2.7k Ω 1/4W J
R924 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R925 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R926 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R927 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R928 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R929 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R930 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R931 QRL027J-100 OMF RESISTOR 10 Ω 2W J
R933 QRJ146J-272X UNF C RESISTOR 2.7k Ω 1/4W J
R934 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R935 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R936 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R937 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R938 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R939 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R940 QRJ146J-3R3X UNF C RESISTOR 3.3 Ω 1/4W J
R943 QRJ146J-222X UNF C RESISTOR 2.2k Ω 1/4W J
R944 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R945 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R946 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R953 QRJ146J-222X UNF C RESISTOR 2.2k Ω 1/4W J
R954 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R955 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R956 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R957 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R958 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R959 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R960 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R961 QRZ9005-220X FUSI RESISTOR 22 Ω
R962 QRZ9005-220X FUSI RESISTOR 22 Ω
R963 QRJ146J-222X UNF C RESISTOR 2.2k Ω 1/4W J
R965 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R966 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R967 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R968 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R969 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R971 QRJ146J-120X UNF C RESISTOR 12 Ω 1/4W J
R973 QRJ146J-332X UNF C RESISTOR 3.3k
Ω 1/4W J
R975 QRJ146J-220X UNF C RESISTOR 22
Ω 1/4W J
R976 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R977 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R978 QRE141J-133Y C RESISTOR 13k Ω 1/4W J
R979 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
R980 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R981 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R982 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R983 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R984 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R985 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R987 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
 Symbol No. Part No. Part Name Description Local
R993 QRE141J-622Y C RESISTOR 6.2k Ω 1/4W J
R994 QRE141J-512Y C RESISTOR 5.1k Ω 1/4W J
R995 QRE141J-133Y C RESISTOR 13k Ω 1/4W J
R996 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R997 QRE141J-153Y C RESISTOR 15k Ω 1/4W J
R998 QRE141J-562Y C RESISTOR 5.6k
Ω 1/4W J
R999 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
 T2 QQT0281-002 POWER TRANSF
CN55 QGD2501C1-05Z CONNECTOR (1-5)
CN71 QGB2510J1-06 CONNECTOR B-B (1-6)
CN72 QGB2510K1-06 CONNECTOR B-B (1-6)
CN81 QGB2510J1-06 CONNECTOR B-B (1-6)
CN82 QGB2510K1-06 CONNECTOR B-B (1-6)
CN101 QGB2510J1-04 CONNECTOR B-B (1-4)
CN201 QGB2510J1-12 CONNECTOR B-B (1-12)
CN241 QGB2510J1-10 CONNECTOR B-B (1-10)
CN301 QGB2510J1-04 CONNECTOR B-B (1-4)
CN303 QGB2510J1-18 CONNECTOR B-B (1-18)
CN334 QGF1205C1-06 CONNECTOR FFC/FPC (1-6)
CN400 QGF1205C1-09 CONNECTOR FFC/FPC (1-9)
CN402 QGF1205C1-05 CONNECTOR FFC/FPC (1-5)
CN601 QGB2510J1-07 CONNECTOR B-B (1-7)
CN811 QGA3901F2-03 CONNECTOR W-B (1-3)
CN931 QGD2501C1-04Z CONNECTOR (1-4)
CN932 QGD2501C1-03Z CONNECTOR (1-3)
EP1 E409182-001SM GRAND TERMINAL
EP51 QNZ0136-001Z EARTH PLATE
EP91 E406523-001SM GND BKT
EP901 QNZ0136-001Z EARTH PLATE
EP902 QNZ0136-001Z EARTH PLATE
FC1 QNG0020-001Z FUSE CLIP
FC2 QNG0020-001Z FUSE CLIP
FC3 QNG0020-001Z FUSE CLIP
FC4 QNG0020-001Z FUSE CLIP
FC61 QNG0020-001Z FUSE CLIP
FC62 QNG0020-001Z FUSE CLIP
FC63 QNG0020-001Z FUSE CLIP
FC64 QNG0020-001Z FUSE CLIP
FW51 QUM215-10DGZ4 PARA RIBON WIRE
FW831 QUM134-08DGZ4 PARA RIBON WIRE
FW881 QUM213-44DGZ4 PARA RIBON WIRE
HL901 VYH7237-002 IC HOLDER
HS951 E70306-001 HEAT SINK
HS961 E70306-001 HEAT SINK
HS971 E70306-001 HEAT SINK
J91 QNS0022-001 JACK
 RY1 QSK0098-001 RELAY
TA1 QNZ0079-001Z TAB
TA2 QNZ0079-001Z TAB
 TH71 QAD0095-4R7Z P THERMISTOR 4.7 Ω M
X901 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
Q701 2SC2240-BL/AB/T TRANSISTOR
Q702 2SC2240-BL/AB/T TRANSISTOR
Q703 2SC2240-BL/AB/T TRANSISTOR
Q704 2SC2240-BL/AB/T TRANSISTOR
Q705 KTA1268/GL/-T TRANSISTOR
Q706 KTA1268/GL/-T TRANSISTOR
Q707 KTA1268/GL/-T TRANSISTOR
Q708 KTA1268/GL/-T TRANSISTOR
Q709 KTA1268/GL/-T TRANSISTOR
Q710 KTA1268/GL/-T TRANSISTOR
Q711 KTC3200/GL/-T TRANSISTOR
Q712 KTC3200/GL/-T TRANSISTOR
 Q761 2SD2390/PY/-F6 TRANSISTOR
 Q762 2SD2390/PY/-F6 TRANSISTOR
 Q763 2SB1560/PY/-F6 TRANSISTOR
 Symbol No. Part No. Part Name Description Local
