SPECIFICATION
*1: Measured on AC 110 V, 127 V, 220 V and 240 V
*2: Corresponding to Linear PCM, Dolby Digital, and DTS (with sampling frequency -32 kHz, 44.1 kHz, 48 kHz).
Designs & specifications are subject to change without notice.
Amplifier
Output Power At Stereo Operation Front Channel 100 W*1 per channel, min. RMS, driven into 8
Ω at 1 kHz with no more than 0.8% total
harmonic distortion (IEC268-3/DIN).
At Surround Opera-
tion
Front Channel 100 W*1 per channel, min. RMS, driven into 8
Ω at 1 kHz, with no more than 0.8% total
harmonic distortion.
Center Channel 100 W*1, min. RMS, driven into 8
Ω at 1 kHz, with no more than 0.8% total harmonic
distortion.
Surround Channel 100 W*1 per channel, min. RMS, driven into 8
Ω at 1 kHz, with no more than 0.8% total
harmonic distortion.
Surround Back Channel 100 W*1, min. RMS, driven into 8
Ω at 1 kHz, with no more than 0.8% total harmonic
distortion.
Audio Audio Input Sensitivity/Impedance (1 kHz) DVD IN, VCR 1 IN, VCR 2 IN, TV SOUND/DBS IN, VIDEO:200 mV/47 k
Ω
TAPE/MD IN, CDR IN, CD IN:200 mV/47 kΩ
PHONO IN (MM):2.5 mV/47 kΩ
Audio Input (DIGI-
TAL IN)*2
Coaxial DIGITAL 1 (DVD):0.5 V(p-p)/75 Ω
Optical DIGITAL 2 (CD), DIGITAL 3 (TV), DIGITAL 4 (CDR):-21 dBm to -15 dBm (660 nm ±30
nm)
Audio Output Level ZONE 2 PREOUT:1 V
PREOUT:1 V
Recording Output Level TAPE/MD OUT, CDR OUT, VCR 1 OUT, VCR 2 OUT:200 mV
Digital Output (DIGITAL OUT):Optical Signal wave length:660 nm
Output level:-21 dBm to -15 dBm
Signal-to-Noise Ratio ('66 IHF/'78 IHF) DVD IN, VCR 1 IN, VCR 2 IN, TV SOUND/DBS IN, VIDEO:87 dB/80 dB
TAPE/MD IN, CDR IN, CD IN:87 dB/80 dB
PHONO IN (MM):70 dB/78 dB at OUT (REC)
Frequency Response (8
Ω) DVD IN, VCR 1 IN, VCR 2 IN, TV SOUND/DBS IN, VIDEO:20 Hz to 100 kHz (+1 dB, -
3 dB)
TAPE/MD IN, CDR IN, CD IN:20 Hz to 100 kHz (+1 dB, -3 dB)
PHONO IN (MM):20 Hz to 20 kHz (±1 dB)
RIAA Phono Equalization ±1.0 dB (20 Hz to 20 kHz)
Bass Boost +6 dB ±1.0 dB at 100 Hz
Equalization 63 Hz, 250 Hz, 1 kHz, 4 kHz, 16 kHz: ±8 dB (in 2 dB steps)
Video Video Input Sensitivity/Impedance Composite Video:DVD IN, TV SOUND/
DBS IN, VCR 1 IN, VCR 2 IN, VIDEO
1 V(p-p)/75
Ω
S-video:DVD IN, TV SOUND/DBS IN, VCR
1 IN, VCR 2 IN, VIDEO
(Y: luminance):1 V(p-p)/75 Ω
(C: chrominance, burst):0.286 V(p-p)/75 Ω
Component Video :DVD IN, DBS (VCR 1)
IN
(Y: luminance):1 V(p-p)/75 Ω
(PB/PR):0.7 V(p-p)/75 Ω
Video Output Level Composite Video:VCR 1 OUT, VCR 2
OUT, MONITOR OUT
1 V(p-p)/75 Ω
S-video:VCR 1 OUT, VCR 2 OUT, MONI-
TOR OUT
(Y: luminance):1 V(p-p)/75 Ω
(C: chrominance, burst):0.286 V(p-p)/75 Ω
Composite Video:MONITOR OUT (Y: luminance):1 V(p-p)/75 Ω
(PB/PR):0.7 V(p-p)/75 Ω
Synchronization Negative
Signal-to-Noise Ratio 45 dB
FM tuner (IHF)
Tuning Range 87.50 MHz to 108.00 MHz
Usable Sensitivity Monaural 12.8 dBf (1.2
µV/75 Ω)
50 dB Quieting Sensitivity Monaural 16.0 dBf (1.7
µV/75 Ω)
Stereo 37.5 dBf (20.5
µV/75 Ω)
Stereo Separation at OUT (REC) 35 dB at 1 kHz
AM tuner
Tuning Range 531 kHz to 1 602 kHz (at 9 kHz intervals)
530 kHz to 1 600 kHz (at 10 kHz intervals)
General
Power Requirements AC 110 V/127 V/220 V/230 V - 240 V , adjustable with the voltage selector, 50 Hz/60 Hz
Power Consumption 220 W (at operation) 6.0 W (in standby mode)
Dimensions (W
× H × D) 435 mm × 157 mm × 425 mm
Mass 12.4 kg
