JVC RX-8040B Service Manual

3-17
DSP board
Block No. [0][6]
J1203 QNS0089-001 3.5 JACK
J1360 QNN0548-001 4PIN JACK ASSY
J1380 QNN0600-001 PIN JACK
J1490 QNN0549-001 PIN JACK
J1491 QNN0485-001 PIN JACK
K1 QQR0779-001Z COIL
 Symbol No. Part No. Part Name Description Local
IC601 NJM4565M-WE IC
IC602 NJM4565M-WE IC
IC611 NJM4565M-WE IC
IC612 NJM4565M-WE IC
IC613 NJM4565M-WE IC
IC614 NJM4565M-WE IC
IC621 NJM4565M-WE IC
IC622 NJM4565M-WE IC
IC631 NJM2120M-X IC
IC632 NJM4565M-WE IC
IC633 NJM4565M-WE IC
IC634 NJM4565M-WE IC
IC651 NJM4565M-WE IC
IC661 D601A002BPYP225 IC
IC662 SN74LVC1GU04K-X IC
IC663 SST39VF160-7EA2 IC (FLASH)
IC664 K4S641632H-UC75 IC
IC671 UPD784215AGC244 IC(1-TIME)
IC672 SN74AHCT1G32K-X IC
IC681 JCV8009-W IC
IC682 MN35505-X IC
IC683 SN74AHC2G74T-X IC
IC684 SN74LVC2G241T-X IC
IC691 BA3259HFP-W IC
IC692 MM1563DF-X IC 3.3V Regulator
IC697 CS42518-CQZ-C-W IC
Q2101 2SD2114K/VW/-X TRANSISTOR
Q2102 2SD2114K/VW/-X TRANSISTOR
Q2141 2SD601A/RS/-X TRANSISTOR
Q2142 2SD601A/RS/-X TRANSISTOR
Q2201 2SD2114K/VW/-X TRANSISTOR
Q2202 2SD2114K/VW/-X TRANSISTOR
Q2221 2SD2114K/VW/-X TRANSISTOR
Q2222 2SD2114K/VW/-X TRANSISTOR
Q2223 2SD2114K/VW/-X TRANSISTOR
Q2224 2SD2114K/VW/-X TRANSISTOR
Q2301 2SD2114K/VW/-X TRANSISTOR
Q2341 2SD601A/RS/-X TRANSISTOR
Q2401 2SD2114K/VW/-X TRANSISTOR
Q2421 2SD2114K/VW/-X TRANSISTOR
Q2422 2SD2114K/VW/-X TRANSISTOR
Q2501 2SD2114K/VW/-X TRANSISTOR
Q2701 UN2214-X TRANSISTOR
Q2702 UN2214-X TRANSISTOR
Q2703 UN2214-X TRANSISTOR
Q2704 UN2114-X TRANSISTOR
Q2705 UN2114-X TRANSISTOR
Q2706 UN2114-X TRANSISTOR
Q2708 UN2114-X TRANSISTOR
Q2709 UN2114-X TRANSISTOR
Q2710 UN2214-X TRANSISTOR
C2001 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2002 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2005 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2006 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2009 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2010 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2013 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2014 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2018 NEA70JM-476X E CAPACITOR 47uF 6.3V M
 Symbol No. Part No. Part Name Description Local
C2019 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2020 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2101 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2102 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2109 NEA71HM-475X E CAPACITOR 4.7uF 50V M
C2110 NEA71HM-475X E CAPACITOR 4.7uF 50V M
C2111 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2112 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2113 NCB31HK-331X C CAPACITOR 330pF 50V K
C2114 NCB31HK-331X C CAPACITOR 330pF 50V K
C2115 NCB31HK-272X C CAPACITOR 2700pF 50V K
C2116 NCB31HK-272X C CAPACITOR 2700pF 50V K
C2129 NEA71HM-475X E CAPACITOR 4.7uF 50V M
C2131 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2132 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2133 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2134 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2139 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2140 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2141 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2142 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2143 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2144 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2149 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2150 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2161 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2162 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2163 NDC31HJ-181X C CAPACITOR 180pF 50V J
C2164 NDC31HJ-181X C CAPACITOR 180pF 50V J
C2165 NCB31CK-683X C CAPACITOR 0.068uF 16V K
C2166 NCB31CK-683X C CAPACITOR 0.068uF 16V K
C2167 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2168 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2201 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2202 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2209 NEA71HM-225X E CAPACITOR 2.2uF 50V M
C2210 NEA71HM-225X E CAPACITOR 2.2uF 50V M
C2229 NEA71HM-105X E CAPACITOR 1uF 50V M
C2230 NEA71HM-105X E CAPACITOR 1uF 50V M
C2241 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2242 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2243 NCB31HK-562X C CAPACITOR 5600pF 50V K
C2244 NCB31HK-562X C CAPACITOR 5600pF 50V K
C2245 NFV41HJ-182X MPPS CAPACITOR 1800pF 50V J
C2246 NFV41HJ-182X MPPS CAPACITOR 1800pF 50V J
C2249 NEA71HM-225X E CAPACITOR 2.2uF 50V M
C2250 NEA71HM-225X E CAPACITOR 2.2uF 50V M
C2281 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2282 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2283 NCB31HK-471X C CAPACITOR 470pF 50V K
C2284 NCB31HK-471X C CAPACITOR 470pF 50V K
C2285 NCB31HK-471X C CAPACITOR 470pF 50V K
C2286 NCB31HK-471X C CAPACITOR 470pF 50V K
C2287 NCB31HK-682X C CAPACITOR 6800pF 50V K
C2288 NCB31HK-682X C CAPACITOR 6800pF 50V K
C2301 NCB31HK-272X C CAPACITOR 2700pF 50V K
C2309 NEA71HM-225X E CAPACITOR 2.2uF 50V M
C2323 NCB31HK-562X C CAPACITOR 5600pF 50V K
C2325 NFV41HJ-182X MPPS CAPACITOR 1800pF 50V J
C2341 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2342 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2343 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2349 NEA71HM-225X E CAPACITOR 2.2uF 50V M
C2381 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2382 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2383 NCB31HK-681X C CAPACITOR 680pF 50V K
C2385 NCB31HK-681X C CAPACITOR 680pF 50V K
C2387 NCB31HK-682X C CAPACITOR 6800pF 50V K
C2401 NCB31HK-561X C CAPACITOR 560pF 50V K
C2409 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2411 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2412 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2421 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2422 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2423 NCB31CK-823X C CAPACITOR 0.082uF 16V K
C2425 NFV41HJ-333X MPPS CAPACITOR 0.033uF 50V J
C2429 NEA71HM-475X E CAPACITOR 4.7uF 50V M
C2433 NCB31CK-823X C CAPACITOR 0.082uF 16V K
 Symbol No. Part No. Part Name Description Local
