JVC RX-8040B Service Manual

3-12
Input board
Block No. [0][5]
R1804 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R1805 QRE141J-202Y C RESISTOR 2k Ω 1/4W J
R1806 QRE141J-202Y C RESISTOR 2k Ω 1/4W J
R1809 QRE141J-123Y C RESISTOR 12k Ω 1/4W J
R1810 QRE141J-123Y C RESISTOR 12k Ω 1/4W J
R1811 QRE141J-182Y C RESISTOR 1.8k
Ω 1/4W J
R1812 QRE141J-182Y C RESISTOR 1.8k
Ω 1/4W J
R1813 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R1814 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R1821 QRJ146J-221X UNF C RESISTOR 220 Ω 1/4W J
R1822 QRJ146J-221X UNF C RESISTOR 220 Ω 1/4W J
R1823 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R1824 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R1825 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R1826 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R1827 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R1828 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R1829 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R1830 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R1831 QRE141J-911Y C RESISTOR 910 Ω 1/4W J
R1832 QRE141J-911Y C RESISTOR 910
Ω 1/4W J
R1833 QRE141J-391Y C RESISTOR 390
Ω 1/4W J
R1834 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R1835 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R1836 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R1841 QRJ146J-221X UNF C RESISTOR 220 Ω 1/4W J
R1842 QRJ146J-221X UNF C RESISTOR 220 Ω 1/4W J
R1851 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R1852 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R1853 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R1854 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R1855 QRZ0218-R22 EMIT RESISTOR 0.22 Ω
R1856 QRZ0218-R22 EMIT RESISTOR 0.22 Ω
R1861 QRJ125J-330 UNF C RESISTOR 33 Ω 1/2W J
R1862 QRJ125J-330 UNF C RESISTOR 33 Ω 1/2W J
R1863 QRL027J-100 OMF RESISTOR 10 Ω 2W J
R1864 QRL027J-100 OMF RESISTOR 10 Ω 2W J
R1871 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R1872 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R1873 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R1874 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R1875 QRE141J-201Y C RESISTOR 200 Ω 1/4W J
R1876 QRE141J-201Y C RESISTOR 200 Ω 1/4W J
R1877 QRE141J-201Y C RESISTOR 200 Ω 1/4W J
R1878 QRE141J-201Y C RESISTOR 200 Ω 1/4W J
R1891 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R1892 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R1893 QRE141J-183Y C RESISTOR 18k Ω 1/4W J
R1894 QRE141J-183Y C RESISTOR 18k Ω 1/4W J
R1895 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R1896 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R1901 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R1902 QRE141J-563Y C RESISTOR 56k
Ω 1/4W J
R1903 QRE141J-202Y C RESISTOR 2k Ω 1/4W J
R1905 QRE141J-123Y C RESISTOR 12k
Ω 1/4W J
R1911 QRE141J-182Y C RESISTOR 1.8k
Ω 1/4W J
R1912 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R1921 QRJ146J-221X UNF C RESISTOR 220
Ω 1/4W J
R1922 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R1923 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
R1924 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
R1925 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R1931 QRE141J-911Y C RESISTOR 910
Ω 1/4W J
R1932 QRE141J-391Y C RESISTOR 390
Ω 1/4W J
R1933 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R1941 QRJ146J-221X UNF C RESISTOR 220
Ω 1/4W J
R1951 QRJ146J-100X UNF C RESISTOR 10
Ω 1/4W J
R1952 QRJ146J-100X UNF C RESISTOR 10
Ω 1/4W J
R1953 QRZ0218-R22 EMIT RESISTOR 0.22
Ω
R1961 QRJ125J-330 UNF C RESISTOR 33 Ω 1/2W J
R1962 QRL027J-100 OMF RESISTOR 10
Ω 2W J
R1971 QRE141J-391Y C RESISTOR 390
Ω 1/4W J
R1972 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R1973 QRE141J-201Y C RESISTOR 200
Ω 1/4W J
R1991 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R1993 QRE141J-183Y C RESISTOR 18k Ω 1/4W J
R1994 QRE141J-201Y C RESISTOR 200
Ω 1/4W J
R1995 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
 Symbol No. Part No. Part Name Description Local
VR787 QVP0008-501Z TRIM RESISTOR 500 Ω
VR788 QVP0008-501Z TRIM RESISTOR 500 Ω
L791 QQLZ003-1R0 COIL 1uH
L792 QQLZ003-1R0 COIL 1uH
L1761 QQLZ005-R45 COIL 0.45uH
L1861 QQLZ005-R45 COIL 0.45uH
L1862 QQLZ005-R45 COIL 0.45uH
L1961 QQLZ005-R45 COIL 0.45uH
CN711 QGB2510K1-12 CONNECTOR B-B (1-12)
CN712 QGB2510K1-12 CONNECTOR B-B (1-12)
CN713 QGB2510K1-10 CONNECTOR B-B (1-10)
CN714 QGA2501F1-02 CONNECTOR W-B (1-2)
CN715 QGB2510K1-12 CONNECTOR B-B (1-12)
CN716 QGB2510K1-12 CONNECTOR B-B (1-12)
CN717 QGA2001F1-03 CONNECTOR W-B (1-3)
CN718 QGB2510K1-10 CONNECTOR B-B (1-10)
CN719 QGA2501F1-03 CONNECTOR W-B (1-3)
CN722 QGA2001F1-02 CONNECTOR W-B (1-2)
TH731 QAD0012-202 THERMISTOR 2k
Ω L
TH783 QAD0012-202 THERMISTOR 2k
Ω L
TH784 QAD0012-202 THERMISTOR 2k Ω L
TH831 QAD0012-202 THERMISTOR 2k Ω L
TH832 QAD0012-202 THERMISTOR 2k Ω L
TH901 QAD0012-202 THERMISTOR 2k Ω L
 Symbol No. Part No. Part Name Description Local
IC201 MM1117XF-XE IC
IC202 NJM2246M-X IC
IC241 MM1113XF-X IC
IC242 MM1114XF-X IC
IC243 MM1117XF-XE IC
IC244 NJM2246M-X IC
IC261 NJM2406F-X IC
IC301 NJM4580D-D IC
IC302 TC9164AF-X IC
IC303 NJM4565M-WE IC
IC304 NJM4565M-WE IC
IC305 TC9164AF-X IC
IC306 NJM4565M-WE IC
IC307 TC9459F-X IC
IC308 NJM4565M-WE IC
IC361 MM1504XN-X IC
IC362 MM1502XN-X IC
IC363 MM1502XN-X IC
IC371 TC9163AF-X IC
IC375 TC9163AF-X IC
IC380 TC9162AF-X IC
IC381 TC9459F-X IC
IC382 TC9459F-X IC
IC383 TC9459F-X IC
IC384 TC9459F-X IC
IC386 NJM4565M-WE IC
IC394 NJM4565M-WE IC
IC395 NJM4565M-WE IC
IC396 NJM4565M-WE IC
IC397 NJM4565M-WE IC
IC398 NJM4565M-WE IC
Q201 KTA1267/YG/-T TRANSISTOR
Q202 KRC107S-X DIGI TRANSISTOR
Q203 KRC107S-X DIGI TRANSISTOR
Q204 KTA1267/YG/-T TRANSISTOR
Q205 KRC107S-X DIGI TRANSISTOR
Q206 KRC107S-X DIGI TRANSISTOR
Q207 KTA1267/YG/-T TRANSISTOR
Q241 KTA1267/YG/-T TRANSISTOR
Q242 KRC107S-X DIGI TRANSISTOR
Q243 KRC107S-X DIGI TRANSISTOR
 Symbol No. Part No. Part Name Description Local
