RX-DV3SL
1-20
Pin No.
Symbol
I/O
Function
MN101C49GKG (IC761) : System MICOM
1
25
75
51
100 76
26 50
~
~
~
~
1. Pin layout
2. Pin function
1 VREF - Connect to GND
2 PA0 I NTSTEL(RGBESL)
3 PA1 I VCR S/C SW
4 PA2 I DBS S/C SW
5 PA3 I SAFETY
6 PA4 I SHORT&TH DET (A/D)
7 PA5 I OUTLEVEL DETECT (A/D)
8 PA6 I VCR IN (A/D)
9 PA7 I STB IN (A/D)
10 VREF+ - Reference voltage
11 VDD - VDD
12 OSC2 O External terminal for connected oscirator
13 OSC1 I External terminal for connected oscirator
14 VSS - Connect to GND
15 XI I Connect to GND
16 XO O No connect
17 MMO0 I Connect to GND
18 SBO0 O DI DO
19 SBI0 I DI DI
20 SBT0 O DI CK
21 SBO2 O S2UDT
22 SBI2 I U2SDT
23 SBT2 I SCLK
24 NDK O INTP
25 SYSCLK O CPURST
26 IRQ0 I CS
27 IRQ1 I
28 IRQ2 I PROTECT
29 IRQ3 I RDS SET
30 IRQ4 I DI BUSY
31 IRQ5 I HAEADPHONE
32 GND I Connect to GND
33 NSRT I RESET IN
34 TM0IO O DSP RST
35 TM1IO O DSP RDY
36 TM2IO O AVC OUT
37 TM3IO I AVC IN
38 TM7IO O VIDEO MUTE1
39 P15 O VIDEO MUTE2
40 TM4IO O VIDEO YCMIX
41 P17 O VIDEO RGB
42 SBO1 O DSP COM
43 SBI1 I DSP STAT
