JVC RX-DV3SL Service Manual

RX-DV3SL
1-21
Pin No.
Symbol
I/O
Function
44 SBT1 O DSP CLK
45 CBO3 O VOL DATA
46 SBI3 O VOL LATCH
47 SBT3 O VOL CLK
48 MP3 O D.O.MUTE
49 INT/PROG O INT/PROG
50 KEY0 O HEADPHONE RELAY
51 KEY1 O EEDO
52 KEY2 O EEDI
53 KEY3 O EECK
54 KEY4 O EECS
55 KEY5 O FRONT SPK RELAY
56 KEY6 O CENTER SPK RELAY
57 KEY7 O REAR SPK RELAY
58 NEW O S1RELAY
59 NRE I INH
60 NCS O SLOW L
61 A16 O SLOW M
62 A17 O SYSTEM P.ON
63 A0 O FAN ON/OFF
64 A1 O DVD P.ON
65 A2 O TUNER P.ON
66 A3 O MECHA.ON
67 A4 I/O RDS DATA
68 A5 O RDS CLK
69 A6 O STEREO
70 A7 I TUNER DATAI
71 A8 O TUNER MUTE
72 A9 O TUNER DATA0
73 A10 O TUNER CLK
74 A11 O TUNER CE
75 A12 O S1OUT
76 A13 O SMUTE
77 A14 O DSP ON
78 A15 O VS3
79 LED0 O STBY LED
80 LED1 O FAN ON/OFF1-LOW
81 LED2 O FAN ON/OFF2-MID
82 LED3 O DISC SET
83 LED4 I DISC STOP
84 LED5 O FAN ON/OFF3-HIGH
85 LED6 O No connect
86 LED7 O SW MUTE
87 SDO0 O VIDEO SW1
88 SDO1 O VIDEO SW2
89 SDO2 O VIDEO SW3
90 SDO3 O VIDEO SW4
91 SDO4 O DI RST
92 SDO5 O DI CS
93 SDO6 O No connect
94 SDO7 O LMUTE
95 DAVSS - SW OPEN
96 DA0 I OCDAT
97 DA1 I DWDET
98 DA2 O LOPEN
99 DA3 O LCLOSE
100 DAVDD -
Reference voltage
MN101C49GKG
