JVC RX-E11S

38
Specifications
Designs and specifications are subject to change without
notice.
Specifications
Amplifier
Output Power
At stereo operation:
Front channels: 60 W per channel*, min. RMS, both
channels driven into 6 Ω at 1 kHz with no
more than 10% total harmonic distortion.
(IEC268-3)
At surround operation:
Front channels: 60 W per channel*, min. RMS, driven into
6 Ω at 1 kHz with no more than 10% total
harmonic distortion.
Center channel: 60 W*, min. RMS, driven into 6 Ω at
1 kHz, with no more than 10% total
harmonic distortion.
Surround channels: 60 W per channel*, min. RMS, driven into
6 Ω at 1 kHz, with no more than 10% total
harmonic distortion.
* Measured on AC 110 V, 127 V, 220 V, and 240 V.
Audio
Audio Input Sensitivity/Impedance:
DVR/DVD, VCR, DBS, TV: 170 mV/47 kΩ
Audio Input (DIGITAL IN)*:
Coaxial: DIGITAL IN 1(DVR/DVD):
0.5 V(p-p)/75 Ω
Optical: DIGITAL IN 2(DBS), 3(VCR):
–21 dBm to –15 dBm
(660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS (with
sampling frequency—32 kHz, 44.1 kHz, 48 kHz).
Audio Output Level
DVR, VCR: 170 mV
Signal-to-Noise Ratio (’66 IHF/DIN): 87 dB/62 dB
Frequency Response (6 Ω): 20 Hz to 20 kHz (±1 dB)
Bass Boost: +4 dB ±1 dB at 100 Hz
Equalization:
Center frequency: 63 Hz, 250 Hz, 1 kHz, 4 kHz, 16 kHz
Control range: ±8 dB
Video
Video Input Sensitivity/Impedance:
Composite video: DVR/DVD, VCR, DBS:
1 V(p-p)/75 Ω
S-video: DVR/DVD, VCR, DBS:
Y (luminance): 1 V(p-p)/75 Ω
C (chrominance, burst): 0.3 V(p-p)/75 Ω
Video Output Level/Impedance:
Composite video: DVR, VCR, MONITOR OUT:
1 V(p-p)/75 Ω
S-video: DVR, VCR, MONITOR OUT:
Y (luminance): 1 V(p-p)/75 Ω
C (chrominance, burst): 0.3 V(p-p)/75 Ω
Synchronization: Negative
FM tuner (IHF)
Tuning Range: 87.50 MHz to 108.00 MHz
Usable Sensitivity:
Monaural: 12.8 dBf (1.2 µV/75 Ω)
50 dB Quieting Sensitivity:
Monaural: 16.0 dBf (1.7 µV/75 Ω)
Stereo: 37.5 dBf (20.5 µV/75 Ω)
Stereo Separation at Rec Out: 35 dB at 1 kHz
AM tuner
Tuning Range: 531 kHz to 1 602 kHz (at 9 kHz intervals)
530 kHz to 1 600 kHz (at 10 kHz intervals)
General
Power Requirements: AC 110 V/127 V/220 V/230 V – 240 V ,
adjustable with the voltage selector,
50 Hz/60 Hz
Power Consumption: 120 W (at operation)
5 W (in standby mode)
Dimensions (W x H x D): 435 mm x 70 mm x 325 mm
Mass: 5.6 kg
