Getting started
Y P B P R
COMPONENT VIDEO
MONITOR
OUT
DVR/DVD
IN
VCR
IN
DBS
IN
VCR
OUT
(REC)
IN
(PLAY)
DVR/DVD
IN (PLAY)
VCR
DBS
IN
IN
(PLAY)
OUT
(REC)
DVR/DVD
IN (PLAY)
Åı
Ì
Ç
Î
‰
Ï
7 Connecting a VCR
Turn off all components before making connections.
• When you connect other components, refer also to their manuals.
Å To left/right audio channel output
ı To left/right audio channel input
Ç To composite video input
Î To composite video output
‰ To S-video output
Ï To S-video input
Ì To component video output
• Connect Y, P
B, and PR correctly.
Stereo audio cable
(not supplied)
White
Red
White
Component video cable (not supplied)
Composite video
cable (not supplied)
S-video cable (not supplied)
Red
Green Blue Red
VCR
NOTE
When connecting a VCR to the component video input jacks,
make the component video input setting (VCR VIDEO) correctly
for AV COMPU LINK remote control system. See page 21 for
details.
06-11RX-F10S[J]_f.p65 04.4.22, 15:259
