Getting started
English
TV
DBS
IN
IN
MONITOR
OUT
Y P
B
P
R
COMPONENT VIDEO
MONITOR
OUT
DVR/DVD
IN
VCR
IN
DBS
IN
MONITOR
OUT
VIDEO
S-VIDEO
Å
ı
Ç
‰Î
Stereo audio cable
(not supplied)
Composite video
cable (not supplied)
DBS tuner
Å To left/right audio channel output
ı To composite video output
Ç To S-video output
7 Connecting a TV
Connect the TV to the appropriate MONITOR OUT jacks to view the playback pucture from any other connected video components.
Stereo audio cable
(not supplied)
Red
Component video cable (not supplied)
TV
White
Red
S-video cable (not supplied)
Composite video cable
(not supplied)
Green Blue
White
Red
S-video cable (not supplied)
White
Red
Å To left/right audio channel input
ı To left/right audio channel output
Ç To composite video input
Î To S-video input
‰ To component video input
• Connect Y, P
B, and PR correctly.
IMPORTANT:
Audio signals come out through the MONITOR OUT (L/R) jacks
ONLY when TV Direct is in use (see page 14).
Connect these jacks to the audio input jacks corresponding to the
video connection; otherwise, no sound comes out of the TV
speaker when TV Direct is in use.
TV
VCR
DBS
IN
IN
IN
(PLAY)
DBS
IN
VCR
MONITOR
OUT
IN
(PLAY)
Å
ıÇ
Turn off all components before making connections.
• When you connect other components, refer also to their manuals.
7 Connecting a DBS tuner
