JVC SR-VS20E

4-65
REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION
CAPACITOR
C1001 A C 7H
C1002 A C 8H
C1003 A C 8H
C1004 A C 8H
C1006 A C 8I
C1007 A C 8I
C1008 A C 7I
C1010 A C 7I
C1011 A C 7I
C1021 B C 9J
C1041 A C 9H
C1042 A C 7I
C1043 A C 7I
C1044 A C 7H
C1045 A C 8H
C1047 B C 7E
C1048 A C 8D
C1049 A C 8D
C1050 A C 7D
C1051 A C 8F
C1052 B C 8F
C1053 A C 8F
C1054 B C 8F
C1055 A C 8E
C1056 B C 8E
C1057 A C 8D
C1058 B C 8D
C1059 A C 6H
C1060 B C 6H
C1061 A C 7F
C1062 A C 8F
C1063 A C 8E
C1064 B C 8E
C1067 B C 7E
C1068 B C 8E
C1069 A C 7E
C1070 A C 8E
C1071 A C 6J
C1072 A C 6J
C1073 A C 6J
C1074 A C 6J
C1075 A C 6J
C1501 A C 5H
C1502 A C 5H
C1503 A C 5H
C1504 A C 5H
C1505 A C 5I
C1506 A C 5J
C1507 A C 5J
C1508 B C 5J
C1509 A C 5G
C1510 A C 5G
C1515 A C 4I
C1516 A C 4I
C1517 A C 3I
C1518 A C 3I
C1521 A C 3H
C1522 A C 3J
C1523 A C 4J
C2001 B C 4F
C2002 B C 5F
C2003 B C 4F
C2005 B C 5F
C2006 B C 4F
C2007 B C 4E
C2008 B C 5E
C2009 B C 6E
C2010 B C 4F
C2011 A C 5F
C2014 A C 5E
C2015 B C 5E
C2016 B C 4F
C2017 B C 4G
C2018 A C 4G
C2019 A C 5G
C2020 B C 5E
C2022 A C 4E
C2023 B C 4F
C2024 B C 4E
C2025 B C 4E
C2026 A C 4D
C2027 A C 4E
C2028 A C 4D
C2029 A C 4E
C2031 B C 4F
C2032 B C 3E
C2033 B C 3E
C2036 B C 4F
C2037 B C 4F
C2038 B C 4F
C2039 B C 5F
C2040 B C 4E
C2041 B C 5G
C2042 B C 4F
C2043 B C 4G
C2044 B C 5G
C2046 B C 4F
C2047 B C 4F
C2048 B C 5F
C2051 A C 6G
C2052 B C 6G
C2053 B C 3E
C2054 A C 3E
C2055 A C 6E
C2056 A C 6E
C2057 B C 6F
C2058 A C 6G
C2059 A C 6F
C2060 B C 6F
C2061 B C 6F
C2062 A C 6F
C2101 B C 5G
C2102 A C 5F
C2103 A C 5F
C2104 A C 5F
C2105 B C 5G
C2106 B C 8E
C2107 B C 7E
C2108 A C 7E
C2109 A C 7F
C2110 A C 8F
C2111 A C 5G
C2112 A C 5G
C2113 B C 5F
C2114 B C 5G
C2115 B C 5G
C2116 B C 6E
C2117 B C 6E
C2118 B C 6E
C2119 B C 5F
C3001 B C 5B
C3002 B C 5B
C3003 A C 4B
C3004 A C 5B
C3005 A C 5B
C3006 A C 5B
C3007 A C 5B
C3008 A C 5B
C3009 A C 5B
C3010 A C 4B
C3011 A C 7B
C3012 B C 7B
C3013 A C 4B
C3014 B C 4A
C3015 A C 4B
C3016 A C 4B
C3017 A C 4B
C3101 A C 5B
C3102 A C 5B
C3103 A C 5B
C3106 A C 6D
C3107 B C 6C
C3108 A C 6C
C3109 B C 6C
C3111 B C 6A
C3112 A C 6B
C3113 A C 6B
C3114 A C 6B
C3115 A C 6B
C3116 A C 6B
C3117 B C 6B
C3118 A C 5B
C3119 A C 5B
C3121 B C 6B
C3122 A C 6B
C3123 A C 6B
C3124 A C 6B
C3125 A C 5B
C3126 B C 5B
C3127 B C 5B
C3128 B C 5B
C3131 A C 7B
C3132 A C 7B
C3140 B C 3B
C3141 B C 3B
C3142 A C 3B
C3143 B C 3B
C3144 B C 3B
C3501 B C 7C
C3502 B C 7C
C3503 B C 7C
C3504 A C 7C
C3505 A C 7C
C3506 A C 7C
C3507 B C 7C
C3508 A C 7B
C3509 A C 7B
C3510 A C 7B
C3511 A C 7B
C3512 A C 7B
C3513 A C 7B
C3514 A C 7B
C3515 A C 7C
C3520 A C 8B
C3521 A C 8B
C3522 B C 8B
C3523 A C 8B
C3524 B C 8B
C3525 A C 8B
C3531 B C 6B
C3532 B C 6B
C3533 B C 6B
C3534 B C 6C
C3535 B C 6C
C3536 B C 6B
C3537 B C 7B
C3538 B C 7B
C3539 B C 7B
C3540 B C 7B
C3701 B C 8C
C3702 B C 8C
C3703 B C 8C
C3704 A C 8C
C3705 B C 8C
C3706 A C 8C
C3707 A C 8C
C3708 B C 8C
C3709 A C 8C
C3710 A C 8D
C3711 A C 8D
C3712 A C 7D
C3713 B C 7D
C3714 A C 8D
C3715 B C 8D
C3716 B C 8D
C3717 A C 8D
C3718 A C 8D
C3721 B C 9D
C3722 B C 9D
C3723 B C 9D
C3724 B C 9D
C3725 B C 8D
C3726 B C 9D
C3727 B C 8D
C3728 A C 9D
C3729 A C 9C
C3730 A C 9C
C3731 A C 9D
C3732 B C 8C
C3733 B C 8C
C3734 B C 9C
C3735 B C 9C
C3736 B C 9C
C3737 B C 9C
C3738 B C 9C
C4001 B C 4D
C4002 A C 3D
C4003 B C 4D
C4004 B C 5C
C4005 B C 4C
C4007 A C 6D
C4008 B C 6D
C4009 A C 6C
C4010 B C 6C
C4011 A C 4D
C4012 B C 4D
C4013 B C 4D
C4015 A C 4D
C4016 A C 4D
C4017 A C 6D
C4018 A C 6D
C4020 B C 5C
C4021 B C 4C
C4022 B C 4C
C4023 B C 4D
C4024 B C 4C
C4025 A C 3D
C4026 B C 3C
C4027 B C 4C
C4030 B C 4C
C4031 B C 4C
C4032 B C 5D
C4033 B C 4D
C4034 B C 5D
C4040 B C 3B
C4041 B C 3C
C4042 A C 3C
C4045 A C 3B
C4046 B C 3B
C5053 A C 2E
CONNECTOR
CN1001 A C 10E
CN1002 A C 10I
CN1101 A C 9C
CN1501 A C 10H
CN1502 A C 2I
CN2001 A C 10G
CN3501 A C 10B
CN3701 A C 10C
DIODE
D1001 A C 7H
D1002 A C 9I
D1003 A C 8H
D1501 A C 3H
D2002 B C 5E
D2003 B C 4E
D2004 B C 4E
IC
IC1001 B C 7I
IC1002 A C 9J
IC1003 A C 6I
IC1004 A C 6I
IC1005 A C 8H
IC1006 A C 8I
IC1007 A C 8I
IC1008 A C 8I
IC1009 B C 8D
IC1010 B C 7D
IC1011 A C 7D
IC1501 B C 4I
IC1502 A C 3I
IC1601 A C 5H
IC2001 A C 4F
IC2002 B C 5F
IC2003 B C 8E
IC2004 A C 5G
IC2006 B C 6E
IC2007 B C 5G
IC3001 B C 4B
IC3101 B C 3B
IC3102 A C 3B
IC3103 B C 3B
IC3151 A C 7B
IC3501 A C 7C
IC3502 B C 8B
IC3701 B C 8D
IC3702 B C 9D
IC3703 B C 9D
IC4001 A C 4C
IC4002 B C 3C
JACK
J2001 A D 1B
COIL
L1001 A C 6J
L1011 A C 9G
L1012 A C 8F
L1013 A C 9F
L1015 A C 9E
L1018 A C 6H
L1501 B C 5G
L1502 A C 5G
L2001 B C 3D
L2002 B C 6G
L2003 B C 6F
L2004 A C 6E
L2005 B C 6F
L2006 B C 6F
L2007 A C 7E
L2008 A C 7E
L2009 A C 5E
L2010 A C 4E
L2011 A C 4E
L2015 A C 3D
L3103 B C 6D
L3104 B C 6C
L3111 A C 6B
L3131 A C 6B
L3151 B C 7B
L3531 A C 6B
L3532 A C 6B
L3533 B C 7B
L3534 B C 7B
L3701 B C 7D
L3702 A C 9D
L4001 B C 6D
L4002 B C 6C
L4003 A C 6D
L4004 A C 3B
TRANSISTOR
Q1001 A C 9J
Q1002 A C 8J
Q1011 B C 8E
Q1012 B C 8E
Q1013 A C 8F
Q1014 B C 8F
Q1015 A C 8F
Q1016 B C 8F
Q1017 B C 8F
Q1018 B C 8E
Q1501 A C 4I
Q1602 A C 3I
Q1603 A C 3I
Q3101 A C 5A
Q3102 A C 5B
Q3111 B C 6B
Q3112 B C 5B
Q3113 A C 5B
Q3114 A C 5B
Q3115 B C 6B
Q3131 A C 6B
Q3132 B C 5B
Q3133 B C 5B
Q3501 A C 6C
Q3502 B C 6C
Q3503 B C 7B
RESISTOR
R1002 A C 7H
R1003 A C 7H
R1004 A C 7H
R1005 A C 7H
R1006 A C 7H
R1009 A C 7H
R1010 A C 7H
R1011 A C 7H
R1012 A C 7H
R1013 A C 7H
R1014 A C 7H
R1015 A C 7H
R1018 A C 7H
R1019 A C 8H
R1020 A C 8H
R1021 A C 8H
R1022 A C 8H
R1025 A C 8H
R1026 A C 8H
R1027 A C 8I
R1028 A C 7H
R1029 A C 7H
R1030 A C 8H
R1031 A C 8H
R1032 A C 8I
R1033 A C 8I
R1035 A C 8J
R1036 A C 7H
R1037 A C 8I
R1038 A C 8I
R1041 A C 7J
R1043 A C 7I
R1045 A C 6I
R1046 A C 7I
R1047 A C 7I
R1048 A C 7I
R1049 A C 7I
R1050 B C 6I
R1051 A C 7H
R1052 A C 7H
R1053 A C 7H
R1061 A C 9I
R1062 A C 9I
R1063 A C 9I
R1064 A C 8J
R1065 A C 8J
R1073 A C 6J
R1074 A C 6J
R1075 A C 6J
R1076 A C 6J
R1077 A C 6I
R1078 A C 6I
R1079 A C 6J
R1081 A C 8H
R1082 A C 8H
R1083 A C 8I
R1084 A C 7H
R1085 A C 8H
R1091 B C 8E
R1092 B C 8E
R1093 B C 8F
R1094 B C 8F
R1095 B C 8F
R1096 B C 8F
R1097 B C 8F
R1098 B C 8E
R1099 B C 8E
R1100 A C 8D
R1125 B C 8B
R1126 B C 8B
R1501 B C 3G
R1502 A C 3G
R1503 A C 3H
R1504 A C 3H
R1505 A C 3G
R1506 A C 3G
R1514 A C 3G
R1515 A C 3G
R1516 A C 3G
R1517 A C 5H
R1518 A C 5H
R1519 A C 5H
R1520 A C 5H
R1521 A C 5H
R1522 A C 5H
R1523 A C 5H
R1524 A C 5H
R1525 A C 5H
R1526 A C 5I
R1527 A C 5H
R1528 A C 5I
R1531 A C 5I
R1535 A C 4I
R1536 A C 4I
R1537 A C 4I
R1538 A C 4I
R1539 A C 4I
R1540 A C 5H
R1546 A C 5I
R1547 A C 4I
R1552 A C 4J
R1553 A C 4J
R1558 A C 3J
R1560 A C 4J
R1562 A C 3J
R1563 A C 3J
R1564 A C 3J
R1565 A C 4J
R1566 A C 4I
R1567 A C 3J
R1568 A C 3I
R1569 A C 3I
R1570 A C 3H
R1575 B C 2G
R1576 B C 3G
R1577 B C 3G
R1578 A C 3H
R1579 A C 2H
R1580 A C 2H
R1581 B C 3H
R1582 A C 3H
R1583 A C 3H
R1584 A C 3G
R1585 A C 3G
R1586 A C 3G
R1587 B C 2G
R1588 A C 3H
R1589 A C 2H
R1590 A C 2H
R1591 A C 5G
R1592 A C 5G
R1593 A C 5G
R1594 A C 4J
R1601 B C 9I
R1602 B C 9I
R1603 B C 9I
R1605 B C 9I
R1606 B C 9I
R1607 B C 9I
R1608 B C 9I
R1609 B C 9H
R1611 B C 9H
R1612 B C 9H
R1613 B C 9H
R1614 B C 9H
R1615 B C 9H
R1616 B C 9H
R1617 B C 9H
R1618 B C 9H
R1619 B C 9H
R1631 A C 5H
R1632 A C 5H
R1634 A C 5H
R1635 A C 5H
R1636 A C 5H
R1641 A C 3H
R1642 A C 3I
R1644 A C 2I
R1645 A C 3H
R1646 A C 2I
R1647 A C 2I
R1648 A C 2I
R1649 A C 2I
R1650 A C 2I
R1651 A C 2I
R1653 A C 2I
R1655 A C 2I
R1661 A C 3I
R1662 A C 3I
R1663 A C 3I
R1665 A C 3I
R1666 A C 4I
R1667 A C 3I
R1668 A C 3I
R2009 A C 5F
R2010 B C 5F
R2011 A C 5F
R2012 A C 5F
R2013 B C 5F
R2014 B C 4F
R2015 A C 5F
R2016 B C 5F
R2017 B C 6F
R2018 A C 5F
R2019 A C 5F
R2020 B C 5E
R2021 B C 5E
R2022 B C 5E
R2023 B C 5E
R2027 B C 5E
R2031 B C 4E
R2032 B C 4E
R2033 A C 4G
R2034 B C 4G
R2035 A C 4G
R2036 B C 4G
R2037 B C 5G
R2038 A C 4G
R2039 A C 4G
R2040 A C 5G
R2041 B C 4E
R2042 B C 4E
R2043 A C 4E
R2044 A C 4E
R2046 B C 4E
R2047 B C 4E
R2048 B C 4E
R2049 A C 5D
R2050 B C 5E
R2051 B C 5E
R2052 B C 5E
R2053 A C 3E
R2054 A C 3E
R2055 A C 3E
R2056 A C 3E
R2057 A C 3E
R2058 A C 3E
R2059 A C 3E
R2060 A C 3E
R2061 A C 3E
R2062 A C 3E
R2071 B C 4F
R2072 B C 4F
R2073 B C 4F
R2074 B C 4F
R2084 B C 3E
R2085 B C 3F
R2086 B C 3E
R2087 B C 3F
R2088 B C 3E
R2089 B C 3F
R2098 A C 2B
R2101 B C 9G
R2102 B C 9G
R2103 B C 9G
R2104 B C 9G
R2106 B C 9G
R2107 B C 9G
R2108 B C 9G
R2109 B C 9G
R2110 B C 9G
R2112 B C 9G
R2113 B C 9G
R2114 B C 9G
R2115 B C 9G
R2116 B C 9H
R2117 B C 9H
R2118 B C 9H
R2119 B C 9H
R2121 B C 9H
R2122 B C 9H
R2123 B C 9H
R2124 B C 9H
R2125 B C 9H
R2126 B C 9H
R2138 B C 5G
R2139 B C 5F
R2140 B C 5F
R2141 A C 5F
R2142 A C 5F
R2143 A C 5F
R2144 A C 5E
R2145 B C 5F
R2146 A C 5F
R2148 A C 5F
R2149 A C 5F
R2150 B C 5G
R3003 B C 5B
R3004 B C 5B
R3005 B C 5B
R3007 A C 5B
R3008 A C 4B
R3024 A C 5B
R3025 A C 4B
R3026 A C 4B
R3027 A C 4B
R3028 A C 4B
R3029 A C 4B
R3032 A C 4B
R3033 A C 4B
R3034 A C 4B
R3035 A C 4B
R3048 A C 4B
R3054 B C 4B
R3056 B C 4B
R3057 A C 4B
R3058 A C 4B
R3059 A C 4B
R3060 A C 4B
R3061 B C 4B
R3062 A C 4A
R3063 A C 4B
R3064 A C 4B
R3065 A C 4A
R3069 B C 5B
R3070 A C 4B
R3071 A C 4B
R3072 B C 5B
R3073 A C 5B
R3074 A C 4B
R3075 B C 5B
R3076 A C 4B
R3077 B C 5B
R3078 A C 4B
R3079 A C 4B
R3080 A C 5A
R3081 B C 5A
R3101 A C 5A
R3102 A C 5B
R3103 A C 5B
R3104 A C 5B
R3105 A C 5B
R3106 A C 5B
R3111 B C 6B
R3112 B C 6A
R3113 B C 6B
R3114 B C 6B
R3115 A C 6B
R3116 A C 6B
R3117 A C 6B
R3118 B C 5B
R3119 B C 5B
R3120 B C 5B
R3121 B C 6B
R3122 B C 6B
R3123 A C 5B
R3124 B C 5B
R3125 B C 5B
R3131 B C 6B
R3132 B C 6B
R3133 B C 6B
R3134 B C 6B
R3135 B C 6B
R3136 B C 6B
R3137 A C 5B
R3138 B C 6B
R3139 A C 5B
R3140 A C 5B
R3141 B C 5B
R3142 B C 5B
R3143 B C 5B
R3161 B C 3B
R3162 B C 3B
R3163 B C 4B
R3164 B C 3B
R3168 B C 4B
R3501 B C 7C
R3502 B C 7C
R3503 B C 7C
R3504 A C 7B
R3505 B C 7C
R3506 B C 7B
R3507 A C 7B
R3508 A C 7B
R3509 A C 7B
R3510 A C 7B
R3511 B C 7C
R3512 B C 7C
R3521 B C 6B
R3522 B C 6B
R3523 B C 6C
R3524 B C 6C
R3526 B C 6B
R3527 B C 7B
R3528 B C 7B
R3529 B C 7B
R3531 B C 7C
R3532 B C 7C
R3533 B C 7C
R3534 B C 7C
R3701 B C 8C
R3702 B C 8C
R3703 B C 8C
R3704 B C 8C
R3705 A C 8C
R3706 B C 8D
R3707 B C 8D
R3708 B C 8D
R3709 B C 8D
R3710 B C 8D
R3711 B C 9C
R3712 B C 9D
R3713 B C 9D
R3714 B C 9D
R3715 B C 8D
R3716 B C 8D
R3717 B C 8C
R3718 B C 8C
R3719 B C 9C
R3720 B C 9C
R3721 B C 9D
R3722 B C 9D
R3723 B C 9D
R3724 B C 9D
R3725 B C 9C
R3726 B C 9C
R3727 B C 9C
R3728 B C 9C
R3731 B C 9C
R3732 B C 9C
R3733 B C 9C
R3734 B C 9D
R3735 B C 9C
R3736 B C 9D
R3740 A C 9D
R4001 B C 5D
R4002 B C 5D
R4003 B C 4C
R4004 B C 4C
R4005 B C 4C
R4006 A C 5D
R4007 A C 5D
R4008 A C 5D
R4009 A C 5D
R4010 B C 4C
R4011 B C 4C
R4012 B C 4C
R4013 B C 4C
R4015 A C 4D
R4016 A C 4D
R4017 A C 4D
R4018 A C 4D
R4020 A C 5C
R4021 A C 5C
R4022 A C 5C
R4025 B C 5C
R4026 B C 5C
R4027 B C 5C
R4028 B C 5C
R4029 B C 5C
R4030 B C 5C
R4031 B C 5D
R4032 B C 5C
R4033 B C 5C
R4034 B C 5C
R4035 B C 3C
R4036 A C 3C
R4037 A C 3C
R4038 A C 3C
R4039 A C 3C
COMPONENT PARTS LOCATION GUIDE <DV MAIN>
