# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
5-22
R6721 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W
C6701 NCB21HK-103X CAPACITOR 0.01µF,50V
C6702 NCB21HK-222X CAPACITOR 0.0022µF,50V
C6704 NCB21HK-103X CAPACITOR 0.01µF,50V
C6705 NCB21HK-102X CAPACITOR 0.001µF,50V
C6707 NDC21HJ-470X CAPACITOR 47pF,50V
C6708 NDC21HJ-8R0X CAPACITOR 8pF,50V
C6709 NDC21HJ-1R0X CAPACITOR 1pF,50V
C6713 NCF21CZ-224X CAPACITOR 0.22µF,16V
C6714 NCB21HK-682X CAPACITOR 0.0068µF,50V
C6715 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C6716 NCB21HK-682X CAPACITOR 0.0068µF,50V
C6717 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C6719 QEKJ1CM-106 E CAPACITOR 10µF,16V
C6720 QEKJ1CM-106 E CAPACITOR 10µF,16V
C6721 NCB21HK-103X CAPACITOR 0.01µF,50V
C6723 NCB21HK-103X CAPACITOR 0.01µF,50V
C6724 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
L6701 QQL231J-1R0Y COIL 1µH
L6702 QQL231J-3R3Y COIL 3.3µH
X6701 QAX0443-001 CRYSTAL RESONATOR
K6701 NQR0200-003X FERRITE BEAD
K6702 NQR0200-003X FERRITE BEAD
K6703 NQR0200-003X FERRITE BEAD
K6704 NQR0200-003X FERRITE BEAD
K6705 NQR0200-003X FERRITE BEAD
K6706 NQR0200-003X FERRITE BEAD
K6707 NQR0200-003X FERRITE BEAD
BK1 LP40077-001A BRACKET(BOARD)
CN6701 QGG2502K1-10 HEADER PIN
******************************
S-SUB BOARD ASSEMBLY <15>
PW1 LPA10103-01A S-SUB BOARD ASSY
IC501 JCP8018 IC
or JCP8038 IC
IC502 VC2076DP IC
R503 NRSA02J-221X MG RESISTOR 220Ø,1/10W
R504 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W
R505 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W
R506 NRSA02J-391X MG RESISTOR 390Ø,1/10W
R507 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W
R508 NRSA02J-151X MG RESISTOR 150Ø,1/10W
R509 NRSA02J-162X MG RESISTOR 1.6kØ,1/10W
R510 NRVA02D-102X CMF RESISTOR 1kØ,1/10W
R511 NRVA02D-471X CMF RESISTOR 470Ø,1/10W
R512 NRVA02D-102X CMF RESISTOR 1kØ,1/10W
R513 NRVA02D-152X CMF RESISTOR 1.5kØ,1/10W
R514 NRVA02D-332X CMF RESISTOR 3.3kØ,1/10W
R515 NRVA02D-332X CMF RESISTOR 3.3kØ,1/10W
R516 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R517 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R525 NRSA02J-125X MG RESISTOR 1.2MØ,1/10W
R527 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W
R531 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R532 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R533 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R534 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R535 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R536 NRSA02J-101X MG RESISTOR 100Ø,1/10W
C501 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C502 QEKJ1EM-475 E CAPACITOR 4.7µF,25V
C503 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C504 NCB21EK-104X CAPACITOR 0.1µF,25V
C505 QEKJ1EM-475 E CAPACITOR 4.7µF,25V
C506 NCB21EK-104X CAPACITOR 0.1µF,25V
C507 QEKJ0JM-227 E CAPACITOR 220µF,6.3V
C508 QEPF1HM-474 NP E CAPACITOR 0.47µF,50V
C509 QEKJ1CM-106 E CAPACITOR 10µF,16V
C510 QEKJ0JM-227 E CAPACITOR 220µF,6.3V
C511 NCB21HK-103X CAPACITOR 0.01µF,50V
C512 NCB21HK-103X CAPACITOR 0.01µF,50V
C513 QEKJ1EM-475 E CAPACITOR 4.7µF,25V
C514 NCB21HK-103X CAPACITOR 0.01µF,50V
C515 NCB21HK-103X CAPACITOR 0.01µF,50V
C516 NCB21HK-103X CAPACITOR 0.01µF,50V
C517 NCF21EZ-104X CAPACITOR 0.1µF,25V
C518 NCB21EK-104X CAPACITOR 0.1µF,25V
C519 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C520 QERF1EM-475 E CAPACITOR 4.7µF,25V
C521 QEKJ1EM-475 E CAPACITOR 4.7µF,25V
C522 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C523 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C524 NDC21HG-301X CAPACITOR 300pF,50V
C525 NDC21HG-301X CAPACITOR 300pF,50V
C526 NDC21HJ-101X CAPACITOR 100pF,50V
C527 NDC21HJ-181X CAPACITOR 180pF,50V
C528 NDC21HG-271X CAPACITOR 270pF,50V
C529 NDC21HG-820X CAPACITOR 82pF,50V
C530 NDC21HG-221X CAPACITOR 220pF,50V
C531 NDC21HG-301X CAPACITOR 300pF,50V
C532 NDC21HG-301X CAPACITOR 300pF,50V
C533 NCB21HK-103X CAPACITOR 0.01µF,50V
C534 QETJ0JM-477 E CAPACITOR 470µF,6.3V
C535 NCB21HK-103X CAPACITOR 0.01µF,50V
C551 QEKJ1HM-105 E CAPACITOR 1µF,50V
C552 NCB21HK-103X CAPACITOR 0.01µF,50V
C553 NCB21HK-103X CAPACITOR 0.01µF,50V
C554 QEKJ1HM-105 E CAPACITOR 1µF,50V
C555 NCB21HK-103X CAPACITOR 0.01µF,50V
C556 NCB21HK-103X CAPACITOR 0.01µF,50V
C557 QEKJ1HM-105 E CAPACITOR 1µF,50V
C558 NCB21HK-103X CAPACITOR 0.01µF,50V
C559 NCB21HK-103X CAPACITOR 0.01µF,50V
C560 QEKJ1HM-105 E CAPACITOR 1µF,50V
C561 QEKJ1HM-105 E CAPACITOR 1µF,50V
C563 NCB21HK-103X CAPACITOR 0.01µF,50V
C568 NDC21HJ-680X CAPACITOR 68pF,50V
C569 NDC21HJ-680X CAPACITOR 68pF,50V
C570 NDC21HJ-680X CAPACITOR 68pF,50V
C571 NDC21HJ-680X CAPACITOR 68pF,50V
C572 NDC21HJ-680X CAPACITOR 68pF,50V
C573 NDC21HJ-680X CAPACITOR 68pF,50V
L501 QQL29BJ-100Z COIL 10µH
L503 QQL29BJ-100Z COIL 10µH
L504 QQL29BJ-100Z COIL 10µH
