5-3
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
******************************
FINAL ASSEMBLY <M2>
! 501 LP10331-007A FRONT PANEL ASSY,SR-VS20E
LP10311-008A FRONT PANEL ASSY,SR-VS20EK
501A LP20968-005A CASSETTE DOOR,VHS
501B PQ46448 TORSION SPRING,VHS
501C LP30757-001A BASE(J/S)
501D QYTDSF2608Z SCREW,X3
501E LP30763-007A DOOR(JACK),SR-VS20E
LP30763-008A DOOR(JACK),SR-VS20EK
501F LP30756-002A CASSETTE DOOR(DV)
501G LP40688-001A SPRING(DV)
501J PU60109 CATCHER
! 502 LP10128-004A TOP COVER
503 QYTDST3006M SCREW,X4 TOP COVER(SIDE)
504 QYTDST3006M SCREW,X3 TOP COVER(REAR)
505 LP20617-016A DRUM SUB ASSY
505A LP20030-023A UPPER DRUM ASSY
505B LP40543-001A CAP
505C PDM4444-19-2 WASHER
505D LP40572-001A COLLAR ASSY
505E LP40323-001A CONTACT
505F LP30004-014A COMPRESION SPRING
505G LP40174-001B FPC PLATE
506 PDZ0179-1-4 ROTOR ASSY
507 QYSPSP3006Z SCREW,X2
! 508 QAR0119-001 STATOR ASSY
509 QYSPSPH2606Z SCREW,X2
510 QYTDST2610Z SCREW,X3 DRUM
! 511 LP10156-003B BOTTOM CHASSIS ASSY
511A LP10130-002B BRACKET(1)
511B PEME0834 SPACER (BOARD),X3
511C LP40696-001A HOLDER(BOARD),X2
511D LP40696-002A HOLDER(BOARD)
511E QYTDST3006Z SCREW,X4
512 LP30352-001B BRACKET(DV),MECHA
513 LP20359-001B BASE(2),DV MECHA
514 QYTDST2004Z SCREW,X2 DV MECHA
515 QYTDSF2606Z SCREW,X3 DV MECHA
516 QYTDST3006Z SCREW,X4 BASE(2)
517 LP20939-001C BASE(1),VHS
518 QYTDST3006Z SCREW,X3 BASE(1)
519 QYTDSF3010Z SCREW,BOTTOM CHASSIS
! 520 LP10339-001A REAR COVER
521 QYTDST3006M SCREW,X4 REAR COVER
523 QYTDSF3008M SCREW,JACK
524 QYTDSF3008M SCREW,X4 PERI
525 QYTDSF3008M SCREW,S JACK
527 PQ46617B-1 FOOT ASSY,X2
528 PQ35504 FOOT(2),X2
529 QYTDST3006Z SCREW,X4 FOOT
! 530 QMP4A10-170 POWER CORD,SR-VS20E
! QMP51K0-170-K POWER CORD,SR-VS20EK
531 PQ40413 SPECIAL SCREW,VHS MECHA
532 LP40700-001A SPECIAL SCREW,VHS MECHA
533 LP40226-001A PC SUPPORT,X2
534 PQ21623-2-5 EARTH PLATE(RF)
535 QYTDSF3010Z SCREW,X2 VHS MECHA
537 PQ41556 EARTH PLATE,CASS.H
538 QYTDSF3010Z SCREW,X2 VHS MAIN
539 QYTDST3006Z SCREW,VHS MAIN
540 LY30428-004A CASSETTE HOUSING ASSY,DV
541 QYTDSP2004Z SCREW,X2
542 QYTDST3006Z SCREW,X4 DV MAIN
543 QYTDST3006Z SCREW,X2 SW.RWG
544 QYTDST3006Z SCREW,X2 PRE/REC MDA
546 LP30553-001A EARTH PLATE,DV CASSETTE HOUSING
547 QYTDST2004Z SCREW
548 QAR0121-001 FAN MOTOR
549 QYTDSP4030M SCREW,X2
550 QYNNS4000Z NUT,X2
551 QYWLS4277A0Z SPRING WASHER,X2
553 QYTDSF2608Z SCREW,X13 FRONT BOARD
554 LP30312-001B BRACKET(CHASSIS)
555 QYTDSF3010Z SCREW,X2 BRACKET
556 LP40407-001A KNOB ASSY
557 LP40370-001E ROLLER ARM ASSY
557A PDM4311A-1 ROLLER ASSY
558 PQ45160 INERTIA PLATE
559 LP30760-002A KNOB(JOG)
560 LP30761-002A KNOB(SHUTTLE)
561 LP40253-001B STOPPER
562 QYTDSF2608Z SCREW,X3 JOG
WR1 WJT0005-002A E-CARD WIRE,A/C HEAD CN2001
WR3 QUQ210-0830CC FFC WIRE,DV MAIN CN2601
WR4 QUQ210-0620CC FFC WIRE,DV MAIN CN3014
WR5 QUQ112-1610CG FFC WIRE,FRONT CN7507
WR6 QUQ112-1810CG FFC WIRE,FRONT CN3011
WR7 QJN019-063411 SHI CR C-C WIRE,DV MAIN CN703
WR8 QUQ212-0516CG FFC WIRE,DRUM CN3001
WR9 QUQ212-1910CG FFC WIRE,SW/REG CN5301
WR10 QUQ212-1328CG FFC WIRE,REG CN7508
WR11 QUQ212-1536CG FFC WIRE,REG CN7509
WR12 QJJ001-101400 SIN CR C-C WIRE,DV MAIN CN5323
WR13 QUQ105-2010AA FFC WIRE,DV PRE/REC CN1501
WR14 QUQ105-2610AA FFC WIRE,DV PRE/REC CN2001
WR15 QJJ001-051200 SIN CR C-C WIRE,DV PRE/REC CN5324
WR7002 QUB220-05XLXL SIN TWIST WIRE
