5-7
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
******************************
MECHANISM ASSEMBLY(DV) <M4>
401 LY10062-001B MAIN DECK ASSY
402 LY30358-001A DRUM BASE DECK
403 YQ43893 MINI SCREW,X3
404 LY30343-001A WORM WHEEL 2
405 LY40237-001C ENT.GUIDE BASE ASSY
406 YQ43893 MINI SCREW
407 LY30340-001C MOTOR BRACKET ASSY
408 YQ43893 MINI SCREW,X4
409 LY41190-001B ROTARY ENCODER ASSY
410 YQ43893 MINI SCREW,X2
411 YQ31873B-30 GUIDE RAIL ASSY(SUPPLY)
413 YQ43893 MINI SCREW
414 LY20097-001C GUIDE RAIL ASSY(TAKE UP)
416 YQ43893 MINI SCREW,X4
417 QAR0012-002 CAPSTAN MOTOR
418 LY30002-003A COMPRESSION SPRING
419 LY41390-001A ADJUST NUT
420 LY30345-001A MIDDLE CATCHER ASSY
421 YQ43893 MINI SCREW,X3
422 LY40223-001A ARM GEAR 1 ASSY
423 LY40224-001A COLLAR
424 LY40235-002B CENTERRING ARM ASSY
425 LY10060-002A MAIN CAM
426 YQ44246 SLIT WASHER
427 LY40279-001A ARM GEAR 2 ASSY
428 LY40228-001A CLUTCH LOCK LEVER ASSY
429 LY20102-001A SUB CAM
430 YQ43893 MINI SCREW
431 LY30347-001A CHARGE ARM ASSY
432 YQ44560-1-2 CONNECT GEAR 2
433 YQ43893 MINI SCREW,X2
434 LY40236-001A TENSION CONTROL ARM ASSY
435 LY40233-001A BRAKE CONTROL ARM ASSY
436 YQ44246 SLIT WASHER
437 LY40242-001C BASE PLATE ASSY
438 YQ43893 MINI SCREW
439 YQ43931A REEL DRIVE PULLEY ASSY
441 YQ44246 SLIT WASHER
442 LY40239-001B CENTER GEAR ASSY
443 LY40241-001A TIMING BELT
444 LY40246-001A CLUTCH LOCK GEAR (1)
445 LY30002-009A COMPRESSION SPRING
446 LY40247-001A CLUCH LOCK GEAR (2)
447 YQ43933-2 WASHER
448 LY40248-001A PUSH PLATE
449 YQ44246 SLIT WASHER
450 LYH30012-001B SUB DECK ASSY(G)
450A LY20108-001B PRISM
450B YQ43893 MINI SCREW
451 YQ43893 MINI SCREW,X4
452 LY20109-001B CONTROL PLATE
453 LY40257-001A SUB BRAKE ASSY
454 YQ44246 SLIT WASHER
455 LY40259-001A MAIN BRAKE ASSY(TAKE UP)
456 LY40260-001B MAIN BRAKE ASSY(SUPPLY)
457 LY40255-001A REEL DISK ASSY,X2
458 LY41245-001B TENSION ARM SUB ASSY
459 LY41243-001A TORSION SPRING
460 LY41246-001C BAND ARM PLATE SUB ASSY
461 YQ44246-3 SLIT WASHER
462 YQ43893-7 MINI SCREW
463 LY30370-001E SWING ARM ASSY
464 LY30380-001D EXIT GUIDE ARM ASSY
464A LY41250-001A CLEANER ARM ASSY
465 YQ44246 SLIT WASHER
466 LY30374-001B PINCH ROLLER ARM ASSY
467 YQ44246 SLIT WASHER
468 LY40280-001B REEL COVER ASSY
469 YQ43893 MINI SCREW
470 YDV2089B DRUM ASSY
471 YQ43893 MINI SCREW,X3
475 YMA0024D MECHA ASSY(A)
