5-17
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
C2064 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2121 QEKJ1CM-476 E CAPACITOR 47µF,16V
C2201 NCB21EK-104X CAPACITOR 0.1µF,25V
C2202 NCB21EK-333X CAPACITOR 0.033µF,25V
C2203 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2204 NCB21HK-102X CAPACITOR 0.001µF,50V
C2205 QEKJ1HM-105 E CAPACITOR 1µF,50V
C2207 QEKJ1CM-476 E CAPACITOR 47µF,16V
C2208 QETJ1HM-475 E CAPACITOR 4.7µF,50V
C2213 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2214 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2215 QERF1EM-475 E CAPACITOR 4.7µF,25V
C2216 QEKJ1HM-474 E CAPACITOR 0.47µF,50V
C2217 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2218 QEKJ1HM-474 E CAPACITOR 0.47µF,50V
C2219 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2220 QEKJ1EM-475 E CAPACITOR 4.7µF,25V
C2221 NCB21HK-103X CAPACITOR 0.01µF,50V
C2222 QEKJ1HM-474 E CAPACITOR 0.47µF,50V
C2223 QEKJ1HM-474 E CAPACITOR 0.47µF,50V
C2224 NCB21HK-103X CAPACITOR 0.01µF,50V
C2225 QEKJ1EM-475 E CAPACITOR 4.7µF,25V
C2226 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2227 NCB21CK-104X CAPACITOR 0.1µF,16V
C2228 NCB21CK-104X CAPACITOR 0.1µF,16V
C2229 NDC21HJ-101X CAPACITOR 100pF,50V
C2230 NDC21HJ-101X CAPACITOR 100pF,50V
C2231 NCB21HK-222X CAPACITOR 0.0022µF,50V
C2251 QEKJ1CM-476 E CAPACITOR 47µF,16V
C2252 NCB21HK-103X CAPACITOR 0.01µF,50V
C2253 NCB21CK-104X CAPACITOR 0.1µF,16V
C2254 NCB21CK-104X CAPACITOR 0.1µF,16V
C2255 NDC21HJ-181X CAPACITOR 180pF,50V
C2601 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2602 NDC21HJ-101X CAPACITOR 100pF,50V
C2603 NDC21HJ-101X CAPACITOR 100pF,50V
C2604 QEKJ1CM-476 E CAPACITOR 47µF,16V
C2605 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2606 QEKJ1HM-105 E CAPACITOR 1µF,50V
C2607 QEKJ1HM-105 E CAPACITOR 1µF,50V
C2610 NDC21HJ-101X CAPACITOR 100pF,50V
C2611 NDC21HJ-101X CAPACITOR 100pF,50V
C2612 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2651 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2652 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2653 NDC21HJ-101X CAPACITOR 100pF,50V
C2654 NDC21HJ-101X CAPACITOR 100pF,50V
C2655 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2656 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2657 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2658 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2659 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2660 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2661 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2681 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2682 QEKJ1CM-476 E CAPACITOR 47µF,16V
C2683 QEKJ1CM-476 E CAPACITOR 47µF,16V
C3001 NCB21EK-104X CAPACITOR 0.1µF,25V
C3002 NCB21HK-103X CAPACITOR 0.01µF,50V
C3003 QEKJ1CM-106 E CAPACITOR 10µF,16V
C3004 NCB21EK-104X CAPACITOR 0.1µF,25V
C3008 NCB21HK-102X CAPACITOR 0.001µF,50V
C3010 QEZ0244-229 EDL CAPACITOR 0.0022F,5.5V
C3012 QEKJ0JM-107 E CAPACITOR 100µF,6.3V
C3015 NCB21EK-104X CAPACITOR 0.1µF,25V
C3016 NCB21EK-104X CAPACITOR 0.1µF,25V
C3022 NCB21EK-104X CAPACITOR 0.1µF,25V
C3024 NDC21HJ-220X CAPACITOR,SR-VS20E 22pF,50V
NDC21HJ-120X CAPACITOR,SR-VS20EK 12pF,50V
C3025 QAT3725-300Z TRIM CAPACITOR,CLOCK ADJ,SR-VS20E
C3027 QERF1CM-106 E CAPACITOR 10µF,16V
C3030 QERF1CM-226 E CAPACITOR 22µF,16V
C3031 NCB21EK-104X CAPACITOR 0.1µF,25V
C3032 NCB21EK-104X CAPACITOR 0.1µF,25V
C3033 NCB21EK-104X CAPACITOR 0.1µF,25V
C3036 NDC21HJ-180X CAPACITOR 18pF,50V
C3037 NDC21HJ-120X CAPACITOR 12pF,50V
C3040 NCB21HK-103X CAPACITOR 0.01µF,50V
C3041 NDC21HJ-100X CAPACITOR,SR-VS20EK 10pF,50V
C3042 QETJ0JM-477 E CAPACITOR 470µF,6.3V
C3054 NCB21EK-104X CAPACITOR 0.1µF,25V
C3310 NCB21HK-103X CAPACITOR 0.01µF,50V
C3311 QEKJ1HM-335 E CAPACITOR 3.3µF,50V
C3312 NCB21HK-103X CAPACITOR 0.01µF,50V
C3313 NCB21EK-473X CAPACITOR 0.047µF,25V
C4002 NCB21EK-104X CAPACITOR 0.1µF,25V
C4003 NCB21HK-102X CAPACITOR 0.001µF,50V
C4004 QERF1CM-226 E CAPACITOR 22µF,16V
C4006 QERF0JM-476 E CAPACITOR 47µF,6.3V
C4007 NCB21HJ-102X CAPACITOR 0.001µF,50V
C4008 NCB21AK-105X CAPACITOR 1µF,10V
C4009 NCB21HK-563X CAPACITOR 0.056µF,50V
C4010 NCB21EK-223X CAPACITOR 0.022µF,25V
C4011 NCB21EK-104X CAPACITOR 0.1µF,25V
C4012 NCB21EK-224X CAPACITOR 0.22µF,25V
C4013 NCB21HK-563X CAPACITOR 0.056µF,50V
C4014 NDC21HJ-101X CAPACITOR 100pF,50V
C4015 NDC21HJ-331X CAPACITOR 330pF,50V
C4016 NCB21HK-681X CAPACITOR 680pF,50V
C4017 NCB21HK-222X CAPACITOR 0.0022µF,50V
C6007 QEKJ0JM-337 E CAPACITOR 330µF,6.3V
C6014 NCB21HK-103X CAPACITOR 0.01µF,50V
C6023 NCB21HK-103X CAPACITOR 0.01µF,50V
C6032 NCB21HK-473X CAPACITOR 0.047µF,50V
C6033 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
C6037 QEKJ1CM-106 E CAPACITOR 10µF,16V
C6553 QEKJ1CM-336 E CAPACITOR 33µF,16V
C6555 NCF21EZ-104X CAPACITOR 0.1µF,25V
C7503 QETJ0JM-477 E CAPACITOR 470µF,6.3V
L1 QQL29BJ-100Z COIL 10µH
L3 QQL29BJ-100Z COIL 10µH
L4 QQL29BJ-100Z COIL 10µH
L5 QQR0657-019Z NOISE FILTER
L12 QQR0967-001 COIL 12µH
L13 QQL071J-330Y COIL 33µH
L15 QQL29BJ-100Z COIL 10µH
L17 QQL071J-5R6Y COIL 5.6µH
L18 QQL071J-220Y COIL 22µH
L19 QQL071J-120Y COIL 12µH
L20 QQL071J-680Y COIL 68µH
L24 QQL071J-270Y COIL 27µH
L27 QQL071J-330Y COIL 33µH
