Specifications
GeneralCD/DVDVideo
Amplifier
Tuner
FM
Power supply 220 - 240 V ~ 50/60 Hz
Power consumption 130 W
Net Weight 4 kg
External dimensions (W x H x D) 430 x 72 x 307 mm
Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser, wavelength 650 nm
Video system PAL/NTSC
Frequency response (audio) 140 Hz to 20 kHz
Signal-to-noise ratio (audio) More than 75 dB (1 kHz, 20 kHz LPF/A-Filter)
Dynamic range (audio) More than 75 dB
Harmonic distortion (audio) 0.5 % (1 kHz, at 1W position) (20 kHz LPF)
Video output 1.0 V (p-p), 75 Ω, negative sync., RCA jack x 1
/ SCART (TO TV)
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, RCA jack x 1
(PB)/(PR) 0.7 V (p-p), 75 ohms, RCA jack x 2
HDMI OUT 480p (or 576p)/720p/1080i/1080p
Tuning Range 87.5 - 108.0 MHz (87.50 - 108.00 MHz)
Intermediate Frequency 10.7 MHz
Signal-to Noise Ratio 60 dB (Mono)
Frequency Response 140 - 10,000 Hz
Tuning Range 522 - 1,620 kHz
Intermediate Frequency 450 kHz
Stereo mode 155 W + 155 W (4Ω at 1 kHz, THD 10 %)
Surround mode Front: 155 W + 155 W (THD 10 %)
center*: 155 W
Surround*: 155 W + 155 W (4Ω at 1 kHz, THD 10 %)
Subwoofer*: 225 W (3Ω at 70 Hz, THD 10 %)
Inputs
AUDIO IN, OPTICAL IN, AUX IN, USB Port, TV-AUDIO(SCART)
Outputs MONITOR OUT, HDMI OUT, SCART
COMPONENT VIDEO OUT
Front Speaker Center speaker
Type
1-way 2-Speaker Bass-reflex type 1-way 2-Speaker Bass-reflex type
(Magnetically-shielded type) (Magnetically-shielded type)
Speaker 5.5cm Cone x 2 6.5cm Cone x 2
Impedance 4 Ω 4 Ω
Frequency Response 100 - 20000 Hz 90 -20000 Hz
Sound Pressure Level 79 dB/W•m 82 dB/W•m
Power Handling Capacity 155 W 155 W
Dimensions (W x H x D)
280 x 1106 x 280mm 250 x 85 x 91mm
Weight 3.3kg 0.77 kg
Rear Speaker Subwoofer
Type
1-way Bass-reflex type Bass-reflex type
Speaker 8cm Cone x 1 16cm Cone x 1
Impedance 4 Ω 3 Ω
Frequency Response 90 - 20000 Hz 30 -200 Hz
Sound Pressure Level 75 dB/W•m 72 dB/W•m
Power Handling Capacity 155 W 225 W
Dimensions (W x H x D)
106 x 120 x 102mm 214 x 296 x 332mm
Weight 0.43kg 4.7kg
Items with are measured at Front Speaker Terminals in STEREO mode
(*
Depending on the sound mode
settings and the source, there
may be no sound output.)
AM
Speakers
