9
SPECIFICATIONS
7 Type : Color video monitor
7 Color system : NTSC, PAL
7 Picture tube : 9" measured diagonally,
flat-square type,
90° deflection, in-line gun,
vertical line trio type (phospher
stripe pitch 0.5 mm)
7 Effective screen size : Width 6-7/8" (175 mm)
Height 5-3/8" (137 mm)
Diagonal 8-3/4" (222 mm)
7 Scanning frequency : (H) 15.734 kHz (NTSC)
15.625 kHz (PAL)
(V) 59.94 Hz (NTSC)
50 Hz (PAL)
7 Horizontal resolution : 280 TV lines or more (Y/C input
mode)
7 Input terminals
VIDEO A : Composite video:
1 line, BNC connector x 2,
1 Vp-p, 75 ¸, negative sync
(bridge connection possible,
auto termination)
VIDEO B : Composite video:
1 line, BNC connector x 2,
1 Vp-p, 75 ¸ negative sync
(bridge connection possible,
auto termination)
Y/C-separated:
1 line, mini-DIN 4-pin
connector x 2
Y: 1.0 Vp-p, 75 ¸
C: 0.286 Vp-p, 75 ¸ (NTSC)
0.3 Vp-p, 75 ¸ (PAL)
(bridge connection possible,
auto termination)
* Y/C priority when both
connected
AUDIO A : 1 line (monaural), RCA pin x 2
0.5 V rms, high-impedance
(bridge connection possible)
AUDIO B : 1 line (monaural), RCA pin x 2
0.5 Vrms, high-impedance
(bridge connection possible)
7 External sync : Composite sync
1 line, BNC connector x 2
1 – 4 Vp-p, 75 ¸
(bridge connection possible,
auto termination)
7 Tally/Remote : 1 line, DIN 8-pin x 1
7 Audio power output : 1 W (monaural)
7 Built-in speaker : 3-3/16" (8 cm) round x 1
impedance of 8 ¸
7 Environmental
conditions : Operation temperature:
0 – 40 °C (32 – 104 °F)
Operation humidity:
20 – 80% (non-condensing)
7 Power requirements : 120 V AC, 50/60 Hz or 12 V DC
7 Power consumption : 0.57A (120 V AC)
3.3A (12 V DC )
7 Dimensions : Width 8-3/4" (222 mm)
Height 9-3/8" (236 mm)
Depth 12-1/2" (317 mm)
7 Weight : Approx. 16.3 lbs (approx. 7.4 kg)
7 Accessory : AC power cord [approx. 7.9 ft
(approx. 2.4 m)] x 1
* Illustrations used in this manual are for explanatory purposes only. The appearance of the actual product may differ slightly.
* E. & O. E. Design and specifications subject to change without notice.
