JVC UX-G950VB User Manual

3-15
Switch board
Block No. [0][2]
DVD module board
Block No. [0][3]
K1002 NQR0627-002X FERRITE 1.5K/
100MHz200mA0
.4R
K3301 QQR0621-001Z FERRITE BEADS
K3450 NQR0502-002X FERRITE BEADS
K3451 NQR0502-002X FERRITE BEADS
LF271 QQR0797-002 COIL
LF272 QQR0797-002 COIL
RY201 QSK0192-001 RELAY
WC201 QZW0112-001 WIRE CLAMP
WC202 QZW0112-002 WIRE CLAMP
WR320 QUM155-12DGZ4-E FLAT WIRE
WR321 QUM154-12DGZ4-E FLAT WIRE
WR390 QUB220-20DMHP-E WIRE 950VB,950V
E,950VEN,9
50VEV,650B
,650E,650E
N,650EV
X3001 QAX0711-002Z CRYSTAL 8.000000MHz
 Symbol No. Part No. Part Name Description Local
IC800 KBJ4J BRIDGE DIODE
IC860 KIA78S06P-T IC
IC870 MM3143DN-X IC
Q6800 KRC111S-X TRANSISTOR
Q8000 KRC102S-X DIGI TRANSISTOR
D5100 MA111-X SI DIODE
D5101 MA111-X SI DIODE
D5300 STZC6.8N-X USB ESD DIODE
D5301 MA8056/M/-X Z DIODE
D6800 SLR-343VC-T LED
D6801 SELT2E10C-S LED 950VB,
950VE,
950VE
N,950V
EV,950
VEE
D6802 MA8068/M/-X Z DIODE 950VB,
950VE,
950VE
N,950V
EV,950
VEE
D8000 MA111-X SI DIODE
D8001 RL202-B322-1 SI DIODE
D8002 RL202-B322-1 SI DIODE
D8003 RL202-B322-1 SI DIODE
D8004 RL202-B322-1 SI DIODE
C5000 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5001 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5002 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5003 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5100 NCB31CK-105X C CAPACITOR 1uF 16V K
C5101 NCB31HK-102X C CAPACITOR 1000pF 50V K
C5102 NCB31HK-102X C CAPACITOR 1000pF 50V K
C5301 NCB31HK-222X C CAPACITOR 2200pF 50V K
C5302 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C5303 NDC31HJ-150X C CAPACITOR 15pF 50V J
C5304 NDC31HJ-150X C CAPACITOR 15pF 50V J
C8000 QCZ9133-472 C CAPACITOR 4700pF
C8001 QEZ0797-108Z E CAPACITOR 1000uF
C8100 QFNC2AJ-104Z M CAPACITOR 0.1uF 100V J
C8600 QETN1CM-107Z E CAPACITOR 100uF 16V M
C8700 NCB31CK-105X C CAPACITOR 1uF 16V K
R6501 NRSA63J-202X MG RESISTOR 2k
Ω 1/16W J
R6502 NRSA63J-302X MG RESISTOR 3k
Ω 1/16W J
R6503 NRSA63J-512X MG RESISTOR 5.1k
Ω 1/16W J
R6504 NRSA63J-113X MG RESISTOR 11k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
R6601 NRSA63J-202X MG RESISTOR 2k Ω 1/16W J
R6602 NRSA63J-302X MG RESISTOR 3k
Ω 1/16W J
R6603 NRSA63J-512X MG RESISTOR 5.1k
Ω 1/16W J
R6604 NRSA63J-113X MG RESISTOR 11k
Ω 1/16W J
R6701 NRSA63J-202X MG RESISTOR 2k
Ω 1/16W J
R6702 NRSA63J-302X MG RESISTOR 3k
Ω 1/16W J
R6800 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
 T8001 QQT0253-013 POWER TRANSF
CN502 QGA2501C1-05 CONNECTOR W-B (1-5)
CN503 QGA2501C1-02 CONNECTOR W-B (1-2)
CN602 QGF1208F1-11 CONNECTOR FFC/FPC (1-11)
 CN800 QGA7901C1-02 CONNECTOR W-B (1-2)
CN804 QGA3901C1-05 CONNECTOR W-B (1-5)
CN805 QGA7901C1-02 CONNECTOR W-B (1-2)
EP500 QNZ0136-001Z EARTH PLATE
EP501 QNZ0136-001Z EARTH PLATE
EP502 QNZ0136-001Z EARTH PLATE
EP503 QNZ0136-001Z EARTH PLATE
FT810 QNG0003-001Z FUSE CLIP
FT811 QNG0003-001Z FUSE CLIP
FT820 QNG0003-001Z FUSE CLIP
FT821 QNG0003-001Z FUSE CLIP
J5000 QNS0188-001 JACK
J5100 QNS0188-001 JACK
J5300 QNZ0851-001 USB CONNECTOR
J6800 QSW1060-001 ROTARY SW
K5300 QQR0621-001Z FERRITE BEADS
K5301 QQR0621-001Z FERRITE BEADS
K5302 NQR0627-002X FERRITE 1.5K/
100MHz200mA0.4R
K5303 NQR0627-002X FERRITE 1.5K/
100MHz200mA0.4R
K6500 NQR0627-002X FERRITE 1.5K/
100MHz200mA0.4R
K6600 NQR0627-002X FERRITE 1.5K/
100MHz200mA0.4R
K6700 NQR0627-002X FERRITE 1.5K/
100MHz200mA0.4R
K6800 QQR0621-001Z FERRITE BEADS
 LF800 QQR1321-001 LINE FILTER
 RY800 QSK0129-002 RELAY
S6500 QSW0683-001Z PUSH SW
S6501 QSW0683-001Z PUSH SW
S6502 QSW0683-001Z PUSH SW
S6503 QSW0683-001Z PUSH SW
S6504 QSW0683-001Z PUSH SW
S6600 QSW0683-001Z PUSH SW
S6601 QSW0683-001Z PUSH SW
S6602 QSW0683-001Z PUSH SW
S6603 QSW0683-001Z PUSH SW
S6604 QSW0683-001Z PUSH SW
S6700 QSW0683-001Z PUSH SW
S6701 QSW0683-001Z PUSH SW
S6702 QSW0683-001Z PUSH SW
WC501 QZW0112-002 WIRE CLAMP
WR500 QUM154-22DGZ4-E FLAT WIRE
WR501 WJP0106-001A-E FPC CONNE
WR801 QUM155-14DGZ4-E FLAT WIRE
WR802 QUM154-14DGZ4-E FLAT WIRE
WR803 QUM153-14DGZ4-E FLAT WIRE
 Symbol No. Part No. Part Name Description Local
IC201 LA6502-X IC
IC301 MN2DS0018MA IC
IC302 MM1701CH-X IC
IC303 XC2164A51FM-X IC
IC305 MM3233DF-X IC
IC453 S-80830CNNB-G-W IC
IC505 K4S641632K-UC75 IC
 Symbol No. Part No. Part Name Description Local
