JVC UX-H10

3-4
General assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 OW43-00010-00 CD DOOR LENS PMMA
2 OW66-00010-03 CD DOOR ABS
3 OW39-04200-00 METAL COVER
4 OW97-09019-00 P.C.MAGNET 20495830
5 OW49-04200-00 STABILIZER RING
6 OW55-09019-01B PLASTIC COVER W/O Felt
7 OW48-00010-05 CD TRAY HIPS
8 OW53-00010-00 FUNCTION KNOB ABS
11 OW39-00010-00 PHONE PCB BKT BKT.
12 OW48-04200-01 CD BKT. ABS
13 OW55-00141-02 PUSH ROD NSX01-050
14 OW36-00003-04 CD EJECT SPRING
15 OW16-10101-92L CD DOOR SWITCH DLS-02-1
16 OW36-03232-02 CD DOOR SPRING
17 OW63-00303-01 DAMPER Gear B40GG(x2)
18 OW48-07930-08 CD MECHA COVER Thomson CD
19 OW98-04200-00 CD MECHA Thomson TCP11TK
20 OW35-00003-00 E RING M3
21 OW81-02750-00 CD DAMPER
3140-114-1389-
2(x2)
22 OW81-02750-01 CD DAMPER
3140-114-1390-
2(x2)
24 OW48-00010-01 POWER PCB BKT BKT.
26 OW35-10019-00 FIBRE WASHER F14 X F3 X 1.5mm
27 OW61-00010-03 REAR CABINET
 28 OW30-00020-01S AC POWER CORD
US
UW
 28 OW30-00010-06 AC POWER CORD UT
29 OW81-04200-00 RUBBER FOOT
F11X3mm W/
Tape(x2)
30 OW81-00010-00 RUBBER FOOT 13X6mm
 31 OW49-00010-00 AC CORD HOLDER ABS
 32 OW15-00010-05 TRANS FORMER
33 TA8229K IC OW03-08229-00
34 KTD2058 TRANSISTOR OW01-02058-00
35 OW39-04200-02 HEAT SINK
37 OW48-00010-03 MAIN PCB BKT2
38 OW36-00010-00 CASS KNOB Door Plate
39 OW48-00010-02 MAIN PCB BKT1
40 OW39-04200-04 CASS KNOB BKT
41 OW53-00010-06 CASS KNOB Pause
42 OW53-00010-08 CASS KNOB Stop/Eject
43 OW53-00010-04 CASS KNOB F.FWD
44 OW53-00010-05 CASS KNOB REW.
45 OW53-00010-03 CASS KNOB Play
46 OW53-00010-07 CASS KNOB REC.
47 OW66-00010-02 CASS KNOB Door
48 OW36-00010-01 CASS DOOR SPRIN Spring
49 OW43-00010-01 CASS DOOR LENS Lens
50 OW66-00010-01 CASS DOOR ABS
51 OW48-04200-04 CASS DOOR BKT BKT.
52 OW43-00010-03 DISPLAY LENS PMMA
53 OW55-30000-00 JVC BADGE ABS
54 OW60-00010-01 FRONT CABINET HB
55 OW39-04200-05 PANEL FIXING Plate(x6)
56 OW53-00010-01 POWER KNOB ABS
58 OW53-00010-02 VOLUME KNOB ABS
59 OW94-04200-00 CASS DECK CS-2SC-3222
60 OW91-80010-00 LCD
62 OW43-00010-04 LCD FILTER
63 OW43-00010-02 LIGHT GUIDE PMMA
64 OW68-00010-00 LIGHT GUIDE Paper 0.15TH
65 OW48-00010-00 LCD BKT BKT.
67 OW40-02045-90 SCREW F 2.0 X 4.5
68 OW40-12608-01 SCREW F 2.6 X 8(x18)
69 OW40-13010-01 SCREW F 3.0 X 10(x14)
70 OW40-13008-01 SCREW F 3.0 X 8(x8)
71 OW40-02005-90 SCREW F2.0 X 5(x3)
72 OW40-52610-03 SCREW F2.6 X 10(x4)
73 OW40-12606-01 SCREW F2.6 X 12(x3)
74 OW40-03006-22 SCREW M3 X 6(x6)
75 OW40-13008-41 SCREW F3.0 X 8(x2)
76 OW40-13012-01 SCREW F3.0 X12(x6)
77 OW40-03010-02 SCREW M3 X 10(x2)
78 OW16-10212-00 VOLTAGE SW.
79 OW40-03005-01 SCREW M3 X 5
80 OW35-40007-00 STEEL NUT M3
81 OW35-20001-04 TOOTH WASHER M3
82 OW35-30005-00 SOLDERING LUG F3.5mm L=9mm
 Symbol No. Part No. Part Name Description Local
