JVC UX-H10 Service Manual

3-10
Remote board
Block No. [0][5][0][0]
R130 OW07-25471-60K C RESISTOR 470 RMC 1/16 47
R131 OW07-25681-60K C RESISTOR 680 RMC 1/16 68
R132 OW07-15821-50T C RESISTOR 820 1/8W 52MM T
R133 OW07-15102-50T C RESISTOR 1K 1/8W 52MM T.
R134 OW07-25220-60K C RESISTOR 22 RMC 1/16 220
R135 OW07-15220-50T C RESISTOR 22 1/8W 52MM T.
R136 OW07-15471-50T C RESISTOR 470 1/8W 52MM T
R137 OW07-15681-50T C RESISTOR 680 1/8W 52MM T
R138 OW07-15821-50T C RESISTOR 820 1/8W 52MM T
R139 OW07-15102-50T C RESISTOR 1K 1/8W 52MM T.
R140 OW07-15122-50T C RESISTOR 1.2K 1/8W
R141 OW07-15152-50T C RESISTOR 1.5K 1/8W
R149 OW07-25152-60K C RESISTOR 1.5K RMC 1/16
R150 OW07-25152-60K C RESISTOR 1.5K RMC 1/16
R151 OW07-25152-60K C RESISTOR 1.5K RMC 1/16
R167 OW07-25103-60K C RESISTOR 10K RMC 1/16 10
R168 OW07-25103-60K C RESISTOR 10K RMC 1/16 10
R170 OW07-25103-60K C RESISTOR 10K RMC 1/16 10
R171 OW07-25103-60K C RESISTOR 10K RMC 1/16 10
R172 OW07-25103-60K C RESISTOR 10K RMC 1/16 10
R173 OW07-25103-60K C RESISTOR 10K RMC 1/16 10
R174 OW07-25103-60K C RESISTOR 10K RMC 1/16 10
R175 OW07-25103-60K C RESISTOR 10K RMC 1/16 10
R176 OW07-25103-60K C RESISTOR 10K RMC 1/16 10
R178 OW07-25103-60K C RESISTOR 10K RMC 1/16 10
R179 OW07-25001-60K C RESISTOR 0 RMC 1/16 000J
L101 OW09-70102-00C COIL 100UH
L102 OW08-04344-40 FERRITE COIL 4T
L103 OW08-04344-40 FERRITE COIL 4T
J103 OW07-25001-50K RMC SMD 1206 0 1/8 JPTP
J112 OW07-25001-50K RMC SMD 1206 0 1/8 JPTP
J125 OW07-25001-60K C RESISTOR 0 RMC 1/16 000J
J126 OW07-25001-60K C RESISTOR 0 RMC 1/16 000J
J127 OW07-25001-60K C RESISTOR 0 RMC 1/16 000J
J128 OW07-25561-60K C RESISTOR 560 1/16 561JTP
J129 OW07-25001-60K C RESISTOR 0 RMC 1/16 000J
J130 OW07-25001-60K C RESISTOR 0 RMC 1/16 000J
SW101 OW16-10101-08S TACT SWITCH
EVQJAE05R
H=5MM
SW102 OW16-10101-08S TACT SWITCH
EVQJAE05R
H=5MM
SW103 OW16-10101-08S TACT SWITCH
EVQJAE05R
H=5MM
SW104 OW16-10101-08S TACT SWITCH
EVQJAE05R
H=5MM
SW105 OW16-10101-08S TACT SWITCH
EVQJAE05R
H=5MM
SW106 OW16-10101-08S TACT SWITCH
EVQJAE05R
H=5MM
SW107 OW16-10101-08S TACT SWITCH
EVQJAE05R
H=5MM
SW108 OW16-10101-08S TACT SWITCH
EVQJAE05R
H=5MM
SW109 OW16-10101-08S TACT SWITCH
EVQJAE05R
H=5MM
SW110 OW16-10101-08S TACT SWITCH
EVQJAE05R
H=5MM
SW111 OW16-10101-08S TACT SWITCH
EVQJAE05R
H=5MM
SW112 OW16-10101-08S TACT SWITCH
EVQJAE05R
H=5MM
U101 87EP26F-1J13 IC OW03-87261-10W
U102 FM-6038TM2-5A SENSOR OW02-66038-25
X101 OW09-50720-00 CER. RES. ZTA7.2MT
X102 OW04-32768-03S CRYSTAL 32.768 KHZ
XXXXX OW20-41071-22 7PIN CN102 TO CN850
XXXXX OW20-41041-37 4PIN CN103 TO CN260
XXXXX OW20-41102-34 10PIN CN104 TO CN705
XXXXX OW20-41041-33K 4PIN CN105 TO CN601
XXXXX OW25-84070-03 3PIN CN106 TO CN108
XXXXX OW20-41021-46 2PIN
CN107 TO CD
DOO
XXXXX OW91-80010-00 LCD LCD101
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
D501 1N4148 GE DIODE OW02-04148-00C
C501 OW05-00221-00 C CAPACITOR 220 PF
C502 OW05-00221-00 C CAPACITOR 220 PF
C504 OW05-00471-00 C CAPACITOR 470 PF
C505 OW06-10476-00 E CAPACITOR 47MF 10V
C506 OW07-05010-30 C RESISTOR 1 1/16W
C507 OW07-05104-30 C RESISTOR 100K 1/16W
C508 OW09-50455-00J CER RESONATOR ZTB455E
