JVC UX-H10

3-8
Power board
Block No. [0][2][0][0]
CD board
Block No. [0][3][0][0]
TIE3 OW31-50040-50 UL-1007
WIRE 40MM
BLACK
TIE4 OW31-50040-50 UL-1007
WIRE 40MM
BLACK
U201 TA2149BFN IC OW03-02149-01
U260 TC9257F IC OW03-09257-01
U301 AN7312 IC OW03-07312-00
U601 TC9422F IC OW03-09422-00
 U801 TA8229K IC OW03-08229-00
 U851 ML7808FA IC OW03-07808-04
VD201 SVC348-S TUNING DIODE OW02-00348-00 S
VD202 SVC201SPA TUNING DIODE OW02-00201-00 S
VD203 SVC201SPA TUNING DIODE OW02-00201-00 S
X260 OW04-07200-08 CRYSTAL HC-49/US+-20PPM
XXXXX OW20-42052-31 5PIN HEADER CN880 TO CN801
XXXXX OW25-04300-01 CONNECT.BM FM ANT
XXXXX OW29-00010-01 FM ANT. FM PIG ANT
XXXXX OW20-41062-32K 6PIN FOR CASS MECH
XXXXX OW20-61053-22 5PIN FOR CASS HEAD
XXXXX OW25-84050-02 2PIN FOR CN110 TO CN
XXXXX OW29-00010-00 FM ANT. WIRE FOR RF2
XXXXX OW32-92070-20 DW FM OSC.
XXXXX OW81-10001-00 SPONGE FOR L203 204
XXXXX OW02-30005-03 F3MM SUPER LED 102
XXXXX OW02-30005-03 F3MM SUPER LED 103
XXXXX OW28-32010-00 FIBRE TUBE 2 X R372
XXXXX OW28-32010-00 FIBRE TUBE 2 X R863
XXXXX OW28-02010-01 PVC TUBE UL ID F2MM L=10
XXXXX OW28-02013-01 PVC TUBE UL ID F2MM L=13
XXXXX OW84-00003-00A CABLE TIE 4 UL
XXXXX OW94-04200-00 CASS DECK CS-21SC-3222
 ZD201 OW02-50100-00 Z DIODE 10V0.5W
 ZD830 OW02-50091-00 Z DIODE 9.1V0.5W
 ZD860 OW02-50068-00 Z DIODE 6.8V0.5W
 ZD861 OW02-50062-00 Z DIODE 6.2V0.5W
 Symbol No. Part No. Part Name Description Local
 D905 RL202 DIODE RECTIFIER OW02-00202-00
 D906 RL202 DIODE RECTIFIER OW02-00202-00
 D907 RL202 DIODE RECTIFIER OW02-00202-00
 D908 RL202 DIODE RECTIFIER OW02-00202-00
 D909 1N4001 FR DIODE OW02-04001-00
 D910 1N4001 FR DIODE OW02-04001-00
 D911 1N4001 FR DIODE OW02-04001-00
 D912 1N4001 FR DIODE OW02-04001-00
C900 OW05-00104-82 C CAPACITOR 0.1MF +80%-20%
C905 OW05-07223-82A C CAPACITOR 0.022MF
C906 OW05-07223-82A C CAPACITOR 0.022MF
C907 OW05-07223-82A C CAPACITOR 0.022MF
C908 OW05-07223-82A C CAPACITOR 0.022MF
C909 OW05-07223-82A C CAPACITOR 0.022MF
C910 OW05-07223-82A C CAPACITOR 0.022MF
C911 OW05-07223-82A C CAPACITOR 0.022MF
C912 OW05-07223-82A C CAPACITOR 0.022MF
 C913 OW06-25228-00 E CAPACITOR 2200MF 25V
R903 OW07-15391-36T C RESISTOR 390 3W
T902 OW15-00010-05 TRANS FORMER T57-0313001-11
CN901 OW20-42032-20 3PIN CN901 TO CN860
 F901 OW33-57312-03W FUSE T3.15L 250V
 F902 OW33-57202-03W FUSE T2L 250V
XXXXX OW16-10212-00 VOLTAGE SW. SL14-22AM5A
XXXXX OW28-31510-00 FIBRE TUBE FOR D905-D912
XXXXX OW28-06085-01 PVC TUBE FOR YEL
XXXXX OW28-06100-01 PVC TUBE FOR RED
XXXXX OW28-08130-01 PVC TUBE FOR ORG.BLK
XXXXX OW28-04140-01 PVC TUBE
FOR GRE FOR
BAK
 Symbol No. Part No. Part Name Description Local
XXXXX OW28-16020-01 TUBE
FOR VOLTAGE
SW.
XXXXX OW28-00024-00 TUBE
FOR VOLTAGE
SW.
XXXXX OW31-00210-80 UL1672
FOR DUAL
POWER
XXXXX OW31-20050-51 UL1007
FOR DUAL
POWER
XXXXX OW78-00004-05 SOLDERLESS
FOR AC POWER
WI
XXXXX OW39-10001-00A FUSE HOLDER FOR F901 902
XXXXX OW28-00015-01 SHRINKAGE TUBE VOLTAGE SW.
XXXXX OW28-14020-01 TUBE F4 L=20MM UL
XXXXX OW08-04344-50 FERRITE CORE T25 X 15 X 10
XXXXX OW37-00002-00 EYELET F2 X 4MM
XXXXX OW84-00005-00 CABLE TIE 6.5 UL
XXXXX OW84-07635-00 UL CABLE CLAMP UC-1
 Symbol No. Part No. Part Name Description Local
IC701 TC9462F IC OW03-09462-00
IC702 TA2153FN IC OW03-02153-00
IC703 TA2092N IC OW03-02092-00
Q701 2SC945P TRANSISTOR OW01-00945-16 N
Q702 2SC945P TRANSISTOR OW01-00945-16 N
Q703 2SA733P TRANSISTOR OW01-00733-16 N
Q704 2SC1383R TRANSISTOR OW01-01383-18
Q705 2SA733P TRANSISTOR OW01-00733-16 N
D701 1N4148 GE DIODE OW2-04148-00C
C701 OW05-07103-00A C CAPACITOR 0.01MF
C702 OW05-07104-82B C CAPACITOR 0.1MF50V
C703 OW05-07223-82A C CAPACITOR 0.022MF
C704 OW06-16476-00 E CAPACITOR 47MF 16V
C705 OW06-16107-00 E CAPACITOR 100MF 16V
C706 OW06-16106-00 E CAPACITOR 10MF 16V
C707 OW06-16106-01 E CAPACITOR 10MF 16V
C708 OW05-07222-10A C CAPACITOR 2200PF EP050X22
C709 OW05-07473-82A C CAPACITOR 0.047MF
C710 OW06-16226-01 E CAPACITOR 22MF 16V
C711 OW05-07222-10A C CAPACITOR 2200PF EP050X22
C712 OW05-07473-82A C CAPACITOR 0.047MF
C713 OW06-16476-01 E CAPACITOR 47MF 16V
C714 OW06-50105-01 E CAPACITOR 1MF 50V
C715 OW05-07104-82B C CAPACITOR 0.1MF50V
C716 OW05-07473-82A C CAPACITOR 0.047MF
C719 OW06-16476-01 E CAPACITOR 47MF 16V
C720 OW05-07473-82A C CAPACITOR 0.047MF
C721 OW05-00103-00 C CAPACITOR 0.01MF 50V
C722 OW06-16476-01 E CAPACITOR 47MF 16V
C723 OW06-16476-01 E CAPACITOR 47MF 16V
C724 OW06-16227-02 E CAPACITOR 220MF 16V PITCH
C725 OW05-07104-82B C CAPACITOR 0.1MF50V
C726 OW05-07104-82B C CAPACITOR 0.1MF50V
C727 OW05-00103-00 C CAPACITOR 0.01MF 50V
C728 OW05-07104-82B C CAPACITOR 0.1MF 50V
C729 OW05-07104-82B C CAPACITOR 0.1MF 50V
C730 OW05-07104-82B C CAPACITOR 0.1MF 50V
C731 OW05-07473-82A C CAPACITOR 0.047MF
C732 OW05-07473-82A C CAPACITOR 0.047MF
C733 OW05-07102-10A C CAPACITOR 1000PF
C734 OW06-16476-00 E CAPACITOR 47MF 16V
C735 OW06-16107-00 E CAPACITOR 100MF 16V
C736 OW05-07153-20A C CAPACITOR 0.015MF
C737 OW05-07103-00A C CAPACITOR 0.01MF
C738 OW05-07470-00A C CAPACITOR 47PF
C739 OW05-07272-10A C CAPACITOR 2700PF
C740 OW06-16476-00 E CAPACITOR 47MF 16V
C741 OW05-07224-00 C CAPACITOR 0.22MF
C742 OW05-07471-10A C CAPACITOR 470PF
 Symbol No. Part No. Part Name Description Local
