JVC XV-S332SL Service Manual

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
3-14
Electrical parts list (Servo control board) Block No. 02
A
Item Parts Number Parts Name Remarks Area
A
Item Parts Number Parts Name Remarks Area
R208 NRSA63J-223X RES. C.M R411 NRSA63J-472X RES. C.M
R209 NRSA63J-223X RES. C.M R413 NRSA63J-472X RES. C.M
R210 NRSA63J-242X MG.RES C.M R414 NRSA63J-472X RES. C.M
R211 NRSA63J-242X MG.RES C.M R421 NRSA63J-0R0X RES. C.M
R212 NRSA63J-103X RES. C.M R422 NRSA63J-472X RES. C.M
R213 NRSA63J-103X RES. C.M R423 NRSA63J-472X RES. C.M
R214 NRSA63J-103X RES. C.M R424 NRSA63J-472X RES. C.M
R215 NRSA63J-103X RES. C.M R427 NRSA63J-0R0X RES. C.M
R216 NRSA63J-912X MG.RES C.M R428 NRSA63J-472X RES. C.M
R219 NRSA63J-183X MG RESISTOR R431 NRSA63J-472X RES. C.M
R220 NRSA63J-183X MG RESISTOR R432 NRSA63J-472X RES. C.M
R221 NRSA63J-682X RES. C.M R453 NRSA63J-102X RES. C.M
R222 NRSA63J-103X RES. C.M R501 NRSA63J-102X RES. C.M
R223 NRSA63J-912X MG.RES C.M R502 NRSA63J-472X RES. C.M
R251 NRS125J-R47X MG RESISTOK R504 NRSA63J-330X MG RESISTOR
R252 NRSA63J-2R2X MG.RES C.M R506 NRSA63J-330X MG RESISTOR
R253 NRSA63J-0R0X RES. C.M R507 NRSA63J-330X MG RESISTOR
R254 NRSA63J-203X MG RESISTOR R508 NRSA63J-330X MG RESISTOR
R255 NRSA63J-103X RES. C.M R509 NRSA63J-330X MG RESISTOR
R256 NRSA63J-470X MG.RES C.M R510 NRSA63J-330X MG RESISTOR
R258 NRSA63J-0R0X RES. C.M R511 NRSA63J-330X MG RESISTOR
R259 NRSA63J-103X RES. C.M R512 NRSA63J-330X MG RESISTOR
R301 NRSA63J-473X RES. C.M R513 NRSA63J-330X MG RESISTOR
R302 NRSA63J-473X RES. C.M R514 NRSA63J-330X MG RESISTOR
R303 NRSA63J-473X RES. C.M R515 NRSA63J-330X MG RESISTOR
R304 NRSA63J-473X RES. C.M R516 NRSA63J-330X MG RESISTOR
R305 NRSA63J-473X RES. C.M R517 NRSA63J-330X MG RESISTOR
R306 NRSA63J-473X RES. C.M R518 NRSA63J-330X MG RESISTOR
R307 NRSA63J-473X RES. C.M R519 NRSA63J-330X MG RESISTOR
R308 NRSA63J-0R0X RES. C.M R520 NRSA63J-330X MG RESISTOR
R309 NRSA63J-473X RES. C.M R521 NRSA63J-330X MG RESISTOR
R313 NRSA63J-473X RES. C.M R522 NRSA63J-330X MG RESISTOR
R317 NRSA63J-473X RES. C.M R524 NRSA63J-181X RES.I.M
R319 NRSA63J-473X RES. C.M R527 NRSA63J-181X RES.I.M
R320 NRSA63J-0R0X RES. C.M R528 NRSA63J-102X RES. C.M
R321 NRSA63J-473X RES. C.M R529 NRSA63J-181X RES.I.M
R322 NRSA63J-0R0X RES. C.M R532 NRSA63J-102X RES. C.M
R323 NRSA63J-473X RES. C.M R533 NRSA63J-330X MG RESISTOR
R324 NRSA63J-473X RES. C.M R534 NRSA63J-330X MG RESISTOR
R325 NRSA63J-123X MG RESISTOR R535 NRSA63J-330X MG RESISTOR
R326 NRSA63J-473X RES. C.M R536 NRSA63J-330X MG RESISTOR
R327 NRSA63J-105X MG RESISTOR R537 NRSA63J-330X MG RESISTOR
R328 NRSA63J-153X RES. C.M R538 NRSA63J-330X MG RESISTOR
R329 NRSA63J-473X RES. C.M R539 NRSA63J-330X MG RESISTOR
R330 NRSA63J-473X RES. C.M R540 NRSA63J-330X MG RESISTOR
R331 NRSA63J-473X RES. C.M R541 NRSA63J-0R0X RES. C.M
R332 NRSA63J-102X RES. C.M R542 NRSA63J-0R0X RES. C.M
R333 NRSA63J-682X RES. C.M R543 NRSA63J-0R0X RES. C.M
R334 NRSA63J-102X RES. C.M R545 NRSA63J-472X RES. C.M
R336 NRSA63J-273X MG RESISTOR R546 NRSA63J-181X RES.I.M
R337 NRSA63J-273X MG RESISTOR R547 NRSA63J-222X MG RESISTOR
R338 NRSA63J-472X RES. C.M R548 NRSA63J-332X RES. C.M
R339 NRSA63J-472X RES. C.M R551 NRSA63J-0R0X RES. C.M
R340 NRSA63J-103X RES. C.M R552 NRSA63J-0R0X RES. C.M
R341 NRSA63J-562X RES.I.M R555 NRSA02J-0R0X MG RESISTOR
R402 NRSA63J-472X RES. C.M R571 NRSA63J-330X MG RESISTOR
R403 NRSA63J-0R0X RES. C.M 3,5~7,12,13,15 R572 NRSA63J-0R0X RES. C.M
R404 NRSA63J-0R0X RES. C.M 1,3,4,8,9,11,15,16,19 R573 NRSA63J-0R0X RES. C.M
R405 NRSA63J-0R0X RES. C.M 2,3,8,10,15 R575 NRSA63J-103X RES. C.M
R406 NRSA63J-0R0X RES. C.M 4~7,9,11~14,16~19 R576 NRSA63J-103X RES. C.M
