Machines – Overview
1 Drip grating
2 Drip tray wall
3 Height-adjustable spout
4 Capsule insertion opening
5 Lever
6 Water tank
7 Water tank cover
8 Water filter (optional)
9 Display
10 Controls
11 Spent capsule container
12 Contacts (2x)
13 Lower drip tray
14 Upper drip tray
EN
Small cup
On/Off button
Button symbols:
Large cup
Temperature
reduction
Extra large cup
Rinsing button
°C
CAUTION
Four pointed needles open the capsule in
the machine. Do not reach into the cap-
sule insertion opening in order to avoid
injuries.
With the exeption of the water filter, all illustrated parts
and these original operating instructions form part of
the delivered package. Before starting up the machine,
please check that you have received all parts.
Remove the protective foil
from the drop grating before
first use.
