Kaba 7102 series

1
5
/8" dia.
(41 mm)
2
3
/4"
(70 mm)
1" dia.
(25 mm)
1
/4"
(6 mm)
Top
Bottom
1
1
1
/4"
(32 mm)
1
1
/2"
(38 mm)
3
/4" dia.
(19 mm)
1
/4" dia.*
(6 mm)
1
/4" dia.*
(6 mm)
1
/4" dia.*
(6 mm)
3
3
/4"
(95 mm)
Insert bolt, mark around
face plate of bolt, mortise
to depth required.
B
*BACKSET
*BACKSET
For door with existing 2
1
/8"
(54 mm) dia. hole align template
with this circle.
*IMPORTANT
Drill the four
1
/4"
(6 mm) dia. holes
before all other holes.
2
3
/8"
(60 mm)
Edge of door for 2
3
/8" (60 mm) Backset
(use 2
3
/4" (70 mm) backset for deadbolt cutout)
4" (100 mm) for 2
3
/4" *Backset
3
5
/8" (90 mm) for 2
3
/8" *Backset
1
/8"
(4 mm)
1
/8"
(4 mm)
I
