Visual Feedback Message Definitions
Condition Parameters
Green LED Red LED Duration
Valid pushbutton pressed ON OFF 1/10 sec
Timeout expired OFF ON 1 sec
Valid access ON OFF 1 sec
code keyed
Access granted ON OFF 1/10 sec
Access granted ON ON 1/10 sec
(battery low condition)
Access denied OFF ON 1 sec
Valid programming entry ON OFF 1 sec
Invalid programming OFF ON 1 sec
entry (including
duplicate access code)
Tamper shutdown beginning OFF ON 2 sec
Tamper shutdown state OFF ON 1 sec
Tamper shutdown ending ON OFF 2 sec
Communication starting ON OFF 1 sec
Communication ending ON OFF 1 sec
Communication aborted OFF ON 1 sec
Communication in progress ON ON 1/10 sec
(Alternate) (Alternate)
Hard Reset sequence in ON ON 1/2 sec
progress (Alternate) (Alternate)
Hard Reset sequence ON OFF 2 sec
successfully
Hard Reset sequence failed OFF ON 2 sec
Rate
Once
Once
Once
1 sec
1 sec
Once
Once
Once
Once
10 sec
Once
Once
Once
Once
1 sec
Continuously
ONCE
ONCE
