4 Technical data
4.1 Electrical data
BLUEPLANET GRIDSAVE 92.0TL3-S
DC Input levels Input levels (DC)
MPPrange@Pnom 668 V-1,100 V
Working range
3
591 V-1,100 V
Rated voltage 620 V
Starting voltage 675 V
Open circuit voltage 1,500 V
Max. input current 145 A
Number of strings 1
Max. short-circuit current (ISC max.) 300 A
Input source feedback current 0 A
Polarity safeguard no
AC Output levels Output levels (AC)
Nominal power 92 kVA
Rated voltage 400 V (3P+PE)
Voltage range: continuous operation 300 V - 580 V
Rated current 3 x 132.3 A
Max. continuous current 3 x 132.3 A
Rated frequency 50/60 Hz
Frequency range 45 - 65 Hz
Reactive power 0-100 % Snom
cos phi 0.3 - 1 ind/cap
Number of feed-in phases 3
4.2 General Data
General electrical data
Max. efficiency 98.8 %
European efficiency %
Self consumption: Standby < 10 W
Transformer unit no
Grid monitoring Country-specific
Operation mode Grid-dependent (charge/discharge)
Battery type All intrinsic battery types, e.g. lithium ions
Protection class / over voltage category I / III
General Data
Display LEDs
Controls Button / web server
Menu languages EN; DE; FR; IT; ES; PL; NL; PT; CZ; HU; SL; TR; RO
Interfaces 2 x Ethernet, USB, SD slot, INV OFF, error relay (30V potential free contact)
Communication TCP/IP, Modbus TCP, based on Sunspec
Potential-free relay yes (integrated switch)
DC isolator switch no
3
The minimum DC voltage depends on the instantaneous AC voltage.
Manual Technical data | 4
KACO blueplanet gridsave 92.0 TL3
Page 11
EN
