AC isolator switch no
Cooling temp. regulated fan, max air throughput 364 m³/h
Number of fans 3x outside, 1x inside
Noise emission <60 db(A)
Housing material AL
HxWxD 719 mm x 699 mm x 460 mm
Weight 78.2 kg
Pre-charge L + XL
DC load relay + L + XL
DC load relay - XL
DC fuse
Safety EN 62109-1, EN 62109-2
Interference immunity/interference
emission/grid feedback
EN 61000-6-2 /
62920 -Class A, EN55011 - Class A /
EN61000-3-11, EN 61000-3-12
Certifications
4.3 Environmental data
Item number 1001912 (M) / 1001910 (L) / 1001911 (XL)
Installation distance from coast > 500 m
Installation height 3000m (derating from 2000m)
Ambient temperature -20 °C to +60 °C
Ambient temperature (storage) -25 °C - +60 °C
Power derating from > 45 °C
Protection rating (KACO installation loca-
tion)
IP66 /NEMA 4X
Humidity range (non-condensing) [%] 100%
4 | Technical data Manual
KACO blueplanet gridsave 92.0 TL3
Page 12
