Kaco blueplanet gridsave 92.0 TL3 User Manual

1.3.2 Safety warnings symbols guide
DANGER
High risk
Failure to observe this warning will lead directly to serious bodily injury or death.
WARNING
Potential risk
Failure to observe this warning may lead to serious bodily injury or death.
CAUTION
Low-risk hazard
Failure to observe this warning will lead to minor or moderate bodily injury.
CAUTION
Risk of damage to property
Failure to observe this warning will lead to property damage.
1.3.3 Additional information symbols
NOTE
Useful information and notes
Information that is important for a specific topic or objective, but that is not safety-relevant.
1.3.4 Symbols for instructions
↻ Prerequisite for use
1. Carry out the next step
2. Additional action sequence
ð Interim result of the action
ð End result
1.4 Identification
You will find the name plate with the following data for service and other require-
ments specific to installation on the right side panel of the product:
– Product name
– Part no.
– Serial number
– Date of manufacture
– Technical data
– Disposal information
– Certification marking, CE marking.
KACO new energy
Werner-von-Siemens-Allee1
74172 Neckarsulm
Made in Germany
blueplanet gs 92.0 TL3-S B1 WM OD IIGL
Part number 1001910
Serial number 92.0TL0123456 Year Q4 / 20
Input
DC U max / I max 1100 V / 145 A
U operation range 668 V - 1100 V
Output
Nominal voltage
400 V (3P+PE)
Voltage range continuous operation 300 V - 580 V (Ph-Ph)
Current (maximum continuous) 3 x 132,3 A
Frequency range 45 Hz - 65 Hz
Output
Power
Snom at 400 V Unom 92 000 VA
Smax at 400 V Unom
92 000 VA
Reactive power 0-100% Snom cos phi 0,3-1 ind/cap
Environ-
ment
Temperature range - 20°C ... + 60°C
Protection class / Ingress protection I / IP66 / NEMA 4X
ARC fault circuit protection none
Interface protection according to country specific requirements, details see manual
Grid Support Interactive Inverter
Max. Backfeed Current 0ANo galvanic separation / Ungrounded Arrays Only
Fig.1: Name plate
Manual General information | 1
KACO blueplanet gridsave 92.0 TL3
Page 5
EN
