16
Capacitance measurement
1) Turn the knob to “ ”.
2) Insert the red probe in “ ” terminal, insert the black
probe in “COM” terminal.
3) Contact the probe to the measured circuit or Capacitance,
measure the resistance.
4) Read the measurement result on the screen.
5) WARNING
When measuring Capacitance on the line, disconnect the power supply
and discharge all the high-voltage capacitors. Otherwise, the instrument
may be damaged and may be struck by electric shocks.
