Temperature display
Tf 49.2
o
C
→
Flue temperature (
o
C)
Ti 14.6
o
C
→
Inlet temperature (
o
C) Normally set by
the flue probe during the fresh air purge.
Press the SEND/PRINT button for 1 second to print the full combustion
test.
Press and hold the SEND/PRINT button for approximately 2 seconds to
store the combustion test in the memory.
Press the BACKLIGHT key for one second to “freeze” the readings
before printing.
Fuel display
SET FUEL
→
Set the fuel source.
NATU GAS
→
Fuel source currently selected
Use the / scroll to the required fuel source.
Press the button to select the fuel source. DONE will be briefly
displayed on the bottom line of the display.
Date/Time display
14 : 47 : 15
→
Current time. Can be reset via “Menu”
.
23 / 01 / 14
→
Current date. Can be reset via “Menu”.
