KANE425 manual Page 13
4. USING THE ANALYSER:
4.1 COMBUSTION TESTS:
Insert the tip of the flue probe into the centre of the flue. The readings will
stabilise within 60 seconds assuming the boiler conditions are stable (see
Measuring Flue Gases – Section 7).
The rotary switch can be used to display the following information:
RATIO Display
NAT GAS
→ Can be changed via “Menu”.
R 0.0008
→ CO/CO
2
ratio
CO 52
→ Carbon Monoxide (ppm)
CO2 6.3
→ Carbon Dioxide (%)
Press
to print a full combustion test (also sends to PC if Bluetooth fitted).
Hold
for 2+ seconds to log a full combustion report.
O2/EFF display
O2 9.8
→
Oxygen (%) left after combustion. Should
be 20.9% +
0.1% in fresh air.
TF 145.1
→ Flue temperature (
o
C)
TI 5.4
→
Inlet temperature (
o
C). Normally set by
flue probe during fresh air purge.
Ef C 91.3
→
Defaults to Condensing boiler efficiency
(EfC). Can be changed via “Menu”.
Press to print a full combustion test (also sends to PC if Bluetooth fitted).
