4.4 DIFFERENTIAL TEMPERATURE
Select “Diff Temp” to measure flow, return and differential temperatures
DIFF TEMP display
TEMP
→
Pump stops automatically when dial is
moved to Diff Temp
T1 60.4
→
Use the T1 connection for the flow
temperature sensor
T2 55.2
→
Use the T2 connection for the return
temperature sensor
∆T 5.2
→
Real time temperature difference
Press
to print a differential temperature test (also sends to PC if Bluetooth
fitted).
Hold
for 2+ seconds to log a differential temperature report.
Viewing / printing a differential temperature test
Select MENU / REPORT / TEMP / VIEW
Use
or to select the log number to be printed.
Press to print the test (also sends to PC if Bluetooth fitted).
