KanexPro EXT-HDBTKVM100 - 5 Panel Drawing

HDBaseT 2.0 KVM Extender Set
9
5. Panel Drawing
EXT-HDBTKVM100T
EXT-HDBTKVM100R
EXT-HDBTKVM100T
HDBaseT 2.0 with USBTra nsm it t er
HDBa se T 2. 0 Techno lo gy
HDCP 2.2 Com pl iant
100m a t 4K x2K, 150m a t 10 80P
USB 2. 0 Su pport
Bi-dir ec tional Po C
DC 12 V
Tx Rx
RS232
FW100m / 150m
MODEON LINK HDCP
HDBT OU THDMI IN USB OUT
116 mm
95 mm
22 mm
DC 12V
Tx Rx
HDBT IN
HDMI OUT
USB IN
RS232
EX T- HDBT K VM10 0 R
HD Ba s eT 2 .0 Re ce ive r wi th US B
HDBa se T 2. 0 Tech no lo gy
HDCP 2.2 C om pl iant
100m a t 4K x2K, 150m a t 10 80 P
USB 2. 0 Su pport
Bi-d ir ec tional Po C
FW100m / 150m
MODEON LINK HDCP
116 mm
95 mm
22 mm
