Kärcher CV 30/1 Unit Information

New Unit Information 02.2004
CV 30/1, CV 38/1 Unit functions
Page 11 / 25
1 Brush roller
2 Locking pin (3x) for skid plate
3 Skid plate
4 Roller
5 Running wheel for adjusting height of
brush head
1
2
4 4
3
2
Brush head, view from below
Removing skid plate
– Rotate the locking pins (2) through 90° in an
counter-clockwise direction.
– Pull up and remove the skid plate (3).
2
5

Kärcher CV 30/1 Specifications

General

Airflow	43 l/s
Product type	Upright vacuum
Dust capacity	5.5 L
Product color	Black, Grey
Dust container type	Dust bag
Standard nominal width	- mm
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Maximum input power	850 W
Noise level	66 dB
Dirt separating method	Filtering
Working width (standard brush)	300 mm

Weight and Dimensions

Depth	310 mm
Width	320 mm
Height	1220 mm
Weight	8400 g
