Kärcher CV 30/1 Unit Information

New Unit Information 02.2004
CV 30/1, CV 38/1 Unit functions
Page 13 / 25
Brush head
1 Driving gear
2 Centrifugal clutch drive belt
3 Centrifugal clutch
4 Brush roller drive belt
5 Brush head cover
6 Bumper
7 Rotary height adjustment knob for brush
head
8 Suction hose
9 Suction motor housing
8
7
6
4
3
2
1
Remove brush head cover
– Remove the retaining screws (Item 3,
page 12).
– Remove the brush head cover (5).
– Remove the bumper (6).
3
5
9

Kärcher CV 30/1 Specifications

General

Airflow	43 l/s
Product type	Upright vacuum
Dust capacity	5.5 L
Product color	Black, Grey
Dust container type	Dust bag
Standard nominal width	- mm
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Maximum input power	850 W
Noise level	66 dB
Dirt separating method	Filtering
Working width (standard brush)	300 mm

Weight and Dimensions

Depth	310 mm
Width	320 mm
Height	1220 mm
Weight	8400 g
