Kärcher CV 30/1 Unit Information

New Unit Information 02.2004
CV 30/1, CV 38/1 Unit functions
Page 3 / 25
View from the front
1 Handle
2 Cable hook, top
3 Mains connection cable
4 Foot lever, brush head unlocking device
5 Rollers (2x)
6 Brush head
7 Rotary height adjustment knob for brush
head
8 Brush head cover
9 Dust filter cover
10 Cover latch
11 Unit switch
12 Top cover
13 Suction tube with suction hose
14 Handle column
13
4
5
7
9
12
10
11
8
6
2
3
14
1

Kärcher CV 30/1 Specifications

General

Airflow	43 l/s
Product type	Upright vacuum
Dust capacity	5.5 L
Product color	Black, Grey
Dust container type	Dust bag
Standard nominal width	- mm
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Maximum input power	850 W
Noise level	66 dB
Dirt separating method	Filtering
Working width (standard brush)	300 mm

Weight and Dimensions

Depth	310 mm
Width	320 mm
Height	1220 mm
Weight	8400 g
