Kärcher CV 30/1 Unit Information

New Unit Information 02.2004
CV 30/1, CV 38/1 Unit functions
Page 5 / 25
1 Handle
2 Suction hose
3 Top cover
4 Lower cable hook
5 Clamping lever for handle height
adjustment
6 Suction tube
7 Connection for suction tube
8 Rollers (2x)
Rear view
4
7
15
8
9
8
5
6
3
13
11
12
14
16
10
9 Foot lever, brush head unlocking device
10 Upholstery nozzle (accessories)
11 Rear cover
12 Crevice tool (accessories)
13 Locking device for handle column
14 Mains connection cable
15 Handle column
16 Top cable hook
2
1

Kärcher CV 30/1 Specifications

General

Airflow	43 l/s
Product type	Upright vacuum
Dust capacity	5.5 L
Product color	Black, Grey
Dust container type	Dust bag
Standard nominal width	- mm
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Maximum input power	850 W
Noise level	66 dB
Dirt separating method	Filtering
Working width (standard brush)	300 mm

Weight and Dimensions

Depth	310 mm
Width	320 mm
Height	1220 mm
Weight	8400 g
