Kärcher CV 30/1 Unit Information

New Unit Information 02.2004
Unit functions CV 30/1, CV 38/1
Page 6 / 25
Rear view, rear cover
1 Handle column
2 Retaining screws for rear cover (4x)
3 Rear cover
4 Clamping lever for handle height
adjustment
5 Lower cable hook
6 Locking device for handle column
2
6
5
2
4
2
2
3
Note:
The clamping lever (4) and the lower cable
hook (5) can be replaced once the rear cover
(3) has been removed.
1

Kärcher CV 30/1 Specifications

General

Airflow	43 l/s
Product type	Upright vacuum
Dust capacity	5.5 L
Product color	Black, Grey
Dust container type	Dust bag
Standard nominal width	- mm
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Maximum input power	850 W
Noise level	66 dB
Dirt separating method	Filtering
Working width (standard brush)	300 mm

Weight and Dimensions

Depth	310 mm
Width	320 mm
Height	1220 mm
Weight	8400 g
