Kärcher CV 30/1 Unit Information

New Unit Information 02.2004
Unit functions CV 30/1, CV 38/1
Page 8 / 25
Upper cover open
1 Top cover
2 Unit switch
3 Unit switch connections
4 Control lamp, filter status
5 Housing for control printed circuit board
6 Earth connection plug
7 Mains connection cable
8 Suction hose connection
9 Circlip
10 Suction hose connection socket
7
10
6
5
3
2
1
4
8
9

Kärcher CV 30/1 Specifications

General

Airflow	43 l/s
Product type	Upright vacuum
Dust capacity	5.5 L
Product color	Black, Grey
Dust container type	Dust bag
Standard nominal width	- mm
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Maximum input power	850 W
Noise level	66 dB
Dirt separating method	Filtering
Working width (standard brush)	300 mm

Weight and Dimensions

Depth	310 mm
Width	320 mm
Height	1220 mm
Weight	8400 g
