10 English
ATTENTION
Store device in storage station when
not in use. A lack of stability can cause
device to tip over leaking fluid and
causing floor damage.
Store device in storage station
when not in use.
Remove fresh water tank.
ATTENTION
*Follow recommended dosage instruc-
tions on the detergent.
1 Open fresh water tank lock.
2 Fill fresh water tank with cold or
lukewarm tap water.
Do not exceed "MAX" fill line.
3 KÄRCHER detergents can be add-
ed to fresh water tank as required.*
See chapter Using detergents.
Close tank lock.
Insert fresh water tank until you
hear a click.
Fill fresh water reservoir

Other manuals for Kärcher FC 5

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kärcher FC 5 and is the answer not in the manual?

Kärcher FC 5 Specifications

General IconGeneral
Power sourceAC
AC input voltage220-240 V
AC input frequency50 - 60 Hz
Maximum input power460 W
TypeCylinder vacuum
Product typeUpright vacuum
Cleaning typeWet
Dust capacity0.2 L
Product colorWhite
Dust container typeBagless
Liquid tank capacity0.4 L
Removable handheld vacuum-
International Protection (IP) codeIPX4
Proper useHome
Cleaning surfacesHard floor
Dirt separating methodAqua filtering
Surface coverage per tank60 m²
Working width (standard brush)300 mm
Weight and Dimensions IconWeight and Dimensions
Depth320 mm
Width270 mm
Height1220 mm
Weight5000 g
